Conveyor Section Profile 120+ AL, Variable Length 50-6000 mm - Bosch Rexroth 3842996024
Datasheet (PDF)
The product may differ from the illustration
Aluminum conveyor section profile, size 120 mm, for the VarioFlow plus chain conveyor system, supplied cut to variable length from 50 mm to 6000 mm. The anodized profile forms the load-bearing track structure and accepts slide rails and profile connectors. Required accessories: slide rail and profile connector; cover profile recommended.

Conveyor Section Profile 120+ AL, Variable Length 50-6000 mm - Bosch Rexroth 3842996024

BOSCH REXROTH Original product
Net price (excl. VAT)
€5.39
Excl. 19% VAT , excl. Shipping Cost
Item BRR-3842996024
Manufacturer no. 3842996024
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842996024
Country of originGermany
Customs tariff number76042100
ConditionNew
Add to Wish List Add to Compare
Article
BRR-3842996024
Frequently Bought Together
Total price

The 120+ AL conveyor section profile is the primary structural component for straight conveyor runs in the Bosch Rexroth VarioFlow plus aluminum chain conveyor system. Supplied at variable length to order (50 mm to 6000 mm), it allows track sections to be sized precisely for the available installation space.

  • Flexible length on demand: Cut length freely selectable between 50 mm and 6000 mm - eliminates off-cuts and simplifies project planning.
  • High bending stiffness: Area moments of inertia of 25.83 cm⁴ (x) and 206.79 cm⁴ (y) ensure minimal deflection under load, even on long straight runs.
  • Profile slot 10: Continuous slot along the profile allows sensor brackets, supports, and system accessories to be added without drilling.
  • Anodized aluminum: Lightweight, corrosion-resistant construction suited to assembly and handling systems in industrial and cleanroom environments.

Technical data

AttributeValue
Size [b]120 mm
Length min [L min]50 mm
Length max [L max]6000 mm
Mass [m]2.74 kg/m
Area moment of inertia Ix25.83 cm⁴
Area moment of inertia Iy206.79 cm⁴
Profile slot10
MaterialAluminum, anodized
ColorNatural
Condition on deliveryVariable length
Required accessoriesSlide rail, Profile connector
Recommended accessoriesCover profile
More Information
ExecutionTEC
Manufacturer Nr.3842996024
ManufacturerBosch Rexroth
Country of ManufactureGermany
Weight0.100000
HS-Code76042100
GPSR manufacturer informationBosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Article authenticityOriginal product
Condition of articleNew
Download
File Icon Bosch Rexroth. Katalog Mechanik-Grundelemente (de) (30.56 MB)
File Icon Bosch Rexroth. TSplus Modular Conveyors for Flexible Manufacturing (en) (12.02 MB)
File Icon Bosch Rexroth. Catalog Basic Mechanic Elements (en) (30.55 MB)
File Icon Bosch Rexroth. Aluminum Structural Framing System (en) (29.62 MB)
File Icon Bosch Rexroth. Transfersystem TS 5 (de) (40.69 MB)
File Icon Bosch Rexroth. Transfer system TS 5 (en) (43.75 MB)
File Icon Bosch Rexroth Éléments mécaniques de base (fr) (36.36 MB)
