Fully assembled aluminum vertical curve for the VarioFlow plus chain conveyor system, size 90. It redirects the conveyor line by 5° (radius R500) in the vertical plane. Mounts to the AL section profile using the supplied fastening material.
Vertical curve 90+ AL, 5° R500 for VarioFlow plus - Bosch Rexroth 3842547088
BOSCH REXROTH
Original product
Net price (excl. VAT)
€220.58
Item
BRR-3842547088
Manufacturer no.
3842547088
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.3842547088
Country of originGermany
Customs tariff number84313900
ConditionNew
Article
BRR-3842547088
Frequently Bought Together
-
This Item:
€220.58
-
Safety Cover VarioFlow plus 65 Aluminium Curve 45° - Bosch Rexroth 3842551546
€140.88
-
Cam Wheel 90+ AL, 90° Deflection, VarioFlow Plus - Bosch Rexroth 3842547054
€497.07
Total price
The 90+ AL vertical curve is a fully assembled deflection element for the VarioFlow plus chain conveyor system in the aluminum range. It redirects the conveyor line by 5° (radius R500) in the vertical plane and mounts directly to the AL section profile.
- Supplied fully assembled, incl. fastening material for mounting to the AL section profile
- Anodized aluminum profile for a durable surface
- 5° deflection at radius R500, size 90
Technical data
| Attribute | Value |
|---|---|
| Size [b] | 90 mm |
| Deflection angle [α] | 5° |
| Radius | R500 |
| Dimension [A] | 246.2 mm |
| Actual chain length | 2x 0.24 m |
| Effective sliding rail length | 4x 0.24 m |
| Profile | Aluminum, anodized |
| Profile connector | Steel, galvanized |
| Cross connector | Diecast aluminum |
| Support profile from size 160 | Non-rusting steel 1.4301 |
| Delivery condition | Fully assembled |
| Scope of delivery | Incl. fastening material for mounting to the AL section profile |
| Required accessories | Slide rail: length calculation |
| Weight | 1.01 kg |
| ESD version | TEC |
|---|---|
| Manufacturer Nr. | 3842547088 |
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 1.010000 |
| HS-Code | 84313900 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
