Mobile Digital Microscope 1.3 MP 10-70x 200x with 5-inch Recorder - Dino-Lite AMK4112T-D15

Mobile microscope set without a PC

The Dino-Lite AMK4112T-D15 pairs an AM4112-series USB microscope with the portable D15 recorder. The standalone recorder has a 5-inch display and an SD card slot, so stills and video are captured and stored directly, with no computer attached. The internal battery makes the set independent of mains power for on-site and outdoor work. Magnification runs from 10x to 70x plus 200x in the close-up range.

Key benefits

• 1.3 megapixel microscope with 10-70x and 200x magnification.
• Portable D15 recorder with a 5-inch display, recording straight to SD card, no PC needed.
• Internal battery for mains-independent use in the field.
• 8 switchable white LEDs for even illumination.
• Rugged watertight carrying case for mobile transport.

Technical specifications

• Sensor: 1.3 megapixel
• Magnification: 10-70x plus 200x
• Working distance: standard (no LWD)
• Interface: USB 2.0 (microscope), recording via D15 recorder
• Recorder: 5-inch display, SD card slot, internal battery
• Illumination: 8 switchable white LEDs
• In the box: D15 recorder, watertight carrying case, USB cable, power adapter, battery, bracket

Applications

Mobile inspection in service and maintenance, on-site examination in forensics, field material control, and anywhere documented captures are needed without carrying a computer.

Compatibility

The microscope works either on the D15 recorder or on a PC with DinoCapture 2.0 software. MS and RK series stands provide stable captures.

Standards and origin

Made in Taiwan. Customs code 90118000.
