USB Microscope 1.3 MP 10-70x 200x Switchable White and UV 375nm - Dino-Lite AM4113T-FV2W

One device for white-light and UV-A fluorescence inspection

The AM4113T-FV2W combines two illumination modes in one Premier handheld microscope. In software you switch between white LED light for normal visual inspection and UV-A excitation at 375 nm for fluorescence imaging. The UV LEDs excite the sample and a built-in barrier filter blocks the reflected UV light so that natural colours are preserved.

Key features

• Switchable between white light and UV-A excitation at 375 nm
• UV LEDs and a built-in barrier filter for natural colour rendering under UV
• Magnification 10-70x and 200x, maximum 200x
• 1.3 MP sensor at 1280 x 1024 pixels and up to 30 frames per second
• MicroTouch trigger and calibrated measurement through DinoCapture and DinoXcope

Technical data

• Sensor: 1.3 MP, 1280 x 1024
• Magnification: 10-70x and 200x (maximum 200x)
• Illumination: white LEDs and UV LEDs, 375 nm (UV-A), switchable
• Interface: USB 2.0
• Barrier filter: yes, against reflected UV
• Polarizer: no
• Weight: approx. 0.105 kg

Applications

• Combined white-light and UV-A inspection on the same object
• Forensics, materials and coating inspection
• Research and inspection with fluorescent markers

Compatibility and contents

Works with Dino-Lite MS-W1, RK-02 and MS08B stands and with the BL-CDW backlight. DinoCapture for Windows and DinoXcope for Mac software included.

Standards and origin

Made in Taiwan by AnMo Electronics. Customs code 90118000.
