The product may differ from the illustration
Festo gripper for secure handling and positioning of workpieces in automated processes.
Three-Point Gripper DHDS-50-A - Festo 1259495
FESTO
Original product
Net price (excl. VAT)
€940.41
Excl. 19% VAT ,
excl. Shipping Cost
Available
Fast shipping
Item
FES-1259495
Manufacturer no.
DHDS-50-A
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.DHDS-50-A
EAN4052568229320
Customs tariff number84798997
ConditionNew
Article
FES-1259495
Frequently Bought Together
-
This Item:
€940.41Excl. 19% VAT , excl. Shipping Cost
-
Parallel Gripper HGPT-40-A-B-G1 - Festo 560217
€894.29Excl. 19% VAT , excl. Shipping Cost
-
Three-Point Gripper HGDT-63-A-F-G1 - Festo 560190
€1,338.57Excl. 19% VAT , excl. Shipping Cost
Total price
Festo gripper for secure handling and positioning of workpieces in automated processes. The key technical data of this genuine Festo article are listed below.
| size | 50 |
| Stroke per gripper jaw [mm] | 6,0 |
| Max. exchange precision [mm] | <= 0,2 mm |
| Max. gripper jaw play ax, ay [deg] | <= 0,2 deg |
| Max. gripper jaw play Sz [mm] | <= 0,02 mm |
| Rotational symmetry [mm] | <= 0,2 mm |
| Repeatability grippers [mm] | <= 0,04 mm |
| Quantity Gripper jaws | 3 |
| installation position | arbitrary |
| Principle of operation | double acting |
| Gripper function | 3 point |
| Construction set up | lever<br>Force controlled movement cycle |
| Position detection | For proximity switch |
| Open total gripping force at 6 bar [N] | 840 |
| Close total gripping force at 6 bar [N] | 750 |
| Operating pressure [bar] | 2 to 8 |
| Max. working frequency gripper [Hz] | <= 4 Hz |
| Min. opening time a 6 bar [ms] | 62 |
| Min. closing time at 6 bar [ms] | 55 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Corrosion resistant class KBK | 1 - low corrosion stress |
| ambient temperature [°C] | 5 to 60 |
| Open gripper jaws at gripping force of 6 bar [N] | 280 |
| Close gripper jaws at gripping force at 6 bar [N] | 250 |
| Mass inertia [kg/cm²] | 6,100 |
| Max. force on gripper jaws Fz static [N] | 250 |
| Max. torque on gripper jaws Mx static [Nm] | 24 |
| Max. torque on gripper jaws My static [Nm] | 24 |
| Max. torque on gripper jaws Mz static [Nm] | 24 |
| Lubrication interval guide elements [Mio SP] | 10 |
| Max. mass per external griper finger [g] | 250 |
| Product weight [g] | 920 |
| Fastening type | With Female thread and dowel pin |
| Pneumatic connection | G1/8 |
| Material information | RoHs compliant |
| Cover cap material | PA |
| Housing material | Aluminium wrought alloy<br>Hard anodised |
| Gripper jaws material | High-alloyed stainless steels |
| Manufacturer Nr. | DHDS-50-A |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568229320 |
| Weight | 0.920000 |
| HS-Code | 84798997 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
| Werkstoff | Aluminium |
| Betriebsdruck max [bar] | 8.000000 |
| Pneumatischer Anschluss | G1/8 |
