EMC SQN 80/75 SZ. Compact cylinders, double acting, piston 80 mm, stroke 75 mm

Materials:
Body: anodized aluminium, piston rod: hard chromium plated steel, seal: NBR

Temperature range:
-10 to +60 °C

Operating pressure:
max. 10 bar

Version:
With Magnetic piston

Cylinder switch type:
D

Advantages:
•outstanding value,
•cylinder switches can be mounted on different sides,
•main mounting dimensions identical to SMC Series CQ2A (CQ2)

Piston diameter [mm]	80
Stroke [mm]	75
H (piston rod thread)	M 16
G (compressed air port)	G 3/8"
Repair sets	SQN 80 REP
A [mm]	63,5
B [mm]	53,5
C [mm]	21
D [mm]	25
E [mm]	98
F [mm]	12,5
J [mm]	6,0
K [mm]	22
L [mm]	10,0
M [mm]	77
N [mm]	11,0
O [mm]	17 (11 deep)
P	M 12
P1 [mm]	35,5
Q [mm]	16,0
