VLP 96. Multi stage ejectors to 70% vacuum, G 2", to 6400 l/min

Materials:
Body: anodised aluminium, nozzles: brass, seal: neoprene

Temperature range:
-10°C to max. +100°C, (VLP 96 and VLP 128: -20°C to max. +80°C)

Operating pressure:
1 to 7 bar (optimum 4 - 6 bar)

Pressure gauge connection:
G 1/4"

Advantages:
•higher flow,
•low cost,
•maintenance free,
•high suction performance, ideal for porous materials or to evacuate large volumes

Suction performance [l/min]	6400
Thread Supply air	G 1/2"
Thread vacuum	G 2"
Thread exhaust air	2x G 1-1/2"
Air consumption* [l/min]	1900
Silencer**	FFSD 112
Vacuum meter	MW -163
L [mm]	250
B [mm]	196
H [mm]	95
Evacuation time (1 ltr. to 10%) [s/l]	0,0012
Evacuation time (1 ltr. to 20%) [s/l]	0,0038
Evacuation time (1 ltr. to 30%) [s/l]	0,0075
Evacuation time (1 ltr. to 40%) [s/l]	0,015
Evacuation time (1 ltr. to 50%) [s/l]	0,023
Evacuation time (1 ltr. to 60%) [s/l]	0,038
Evacuation time (1 ltr. to 70%) [s/l]	0,065
Flow at 0% vacuum [l/min]	6.400
Flow at 10% vacuum [l/min]	4.080
Flow at 20% vacuum [l/min]	2.520
Flow at 30% vacuum [l/min]	1.560
Flow at 40% vacuum [l/min]	1.080
Flow at 50% vacuum [l/min]	900
Flow at 60% vacuum [l/min]	600
Temperature range [°C]	-20 to +80
