Festo HGPD-50-A (1132951) Parallel Gripper

Festo
€127,927.00
Excl. 19% VAT , excl. Shipping Cost
Article
FES-1132951

Manufacturer Nr.
HGPD-50-A
Parallel Gripper
Add to Wish List Add to Compare
main product photo
The product may differ from the illustration
Frequently Bought Together
Total price
size 50
Stroke per gripper jaw [mm] 12
Max. exchange precision [mm] <= 0,2 mm
Max. gripper jaw play ax, ay [deg] <= 0,1 deg
Max. gripper jaw play Sz [mm] <= 0,02 mm
Rotational symmetry [mm] <= 0,2 mm
Repeatability grippers [mm] <= 0,05 mm
Quantity Gripper jaws 2
installation position arbitrary
Principle of operation double acting
Gripper function Parallel
Construction set up Inclined plane
Force controlled movement cycle
Position detection For proximity switch
Open total gripping force at 6 bar [N] 944
Close total gripping force at 6 bar [N] 894
Operating pressure [bar] 3 to 8
Operating pressure blocking air [bar] 0 to 0.5
Max. working frequency gripper [Hz] <= 2 Hz
Min. opening time a 6 bar [ms] 90
Min. closing time at 6 bar [ms] 100
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Information about operating and control medium Oiled operation possible (required in further operations)
Corrosion resistant class KBK 2 - moderate corrosion stress
Protection category IP65
ambient temperature [°C] 5 to 60
Open gripper jaws at gripping force of 6 bar [N] 472
Close gripper jaws at gripping force at 6 bar [N] 447
Mass inertia [kg/cm²] 26,19
Max. force on gripper jaws Fz static [N] 2.000
Max. torque on gripper jaws Mx static [Nm] 90
Max. torque on gripper jaws My static [Nm] 60
Max. torque on gripper jaws Mz static [Nm] 50
Lubrication interval guide elements [Mio SP] 5e+006
Max. mass per external griper finger [g] 318
Product weight [g] 1.766
Fastening type With Throughway bore and dowel pin
With Female thread and dowel pin
Selectively:
Female thread and centring sleeve
With Throughway bore and centring sleeve
Pneumatic connection blocking air M5
Pneumatic connection G1/8
Material information RoHs compliant
Cover cap material High-alloyed stainless steels
Housing material aluminium
anodized
Gripper jaws material hardened
Steel
More Information
Manufacturer Nr. HGPD-50-A
Manufacturer Festo
EAN 4052568227166
Weight 2.000000
HS-Code 84798997
GPSR manufacturer information Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
Article authenticity Original product
Condition of article New
