Festo gripper for secure handling and positioning of workpieces in automated processes.
Parallel Gripper HGPD-63-A - Festo 1132954
FESTO Original product
Net price (excl. VAT)
€1,961.08
Item FES-1132954
Manufacturer no. HGPD-63-A
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.HGPD-63-A
EAN4052568227197
Customs tariff number84798997
ConditionNew
Article
FES-1132954
Frequently Bought Together
- This Item: €1,961.08
- Parallel Gripper HGPM-12-EZ-G6 - Festo 197568 €391.69
- Parallel Gripper HGPP-32-A - Festo 525664 €1,276.76
Total price
Festo gripper for secure handling and positioning of workpieces in automated processes. The key technical data of this genuine Festo article are listed below.
| size | 63 |
| Stroke per gripper jaw [mm] | 16 |
| Max. exchange precision [mm] | <= 0,2 mm |
| Max. gripper jaw play ax, ay [deg] | <= 0,1 deg |
| Max. gripper jaw play Sz [mm] | <= 0,02 mm |
| Rotational symmetry [mm] | <= 0,2 mm |
| Repeatability grippers [mm] | <= 0,05 mm |
| Quantity Gripper jaws | 2 |
| installation position | arbitrary |
| Principle of operation | double acting |
| Gripper function | Parallel |
| Construction set up | Inclined plane<br>Force controlled movement cycle |
| Position detection | For proximity switch |
| Open total gripping force at 6 bar [N] | 1.935 |
| Close total gripping force at 6 bar [N] | 1.856 |
| Operating pressure [bar] | 3 to 8 |
| Operating pressure blocking air [bar] | 0 to 0.5 |
| Max. working frequency gripper [Hz] | <= 2 Hz |
| Min. opening time a 6 bar [ms] | 150 |
| Min. closing time at 6 bar [ms] | 162 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Corrosion resistant class KBK | 2 - moderate corrosion stress |
| Protection category | IP65 |
| ambient temperature [°C] | 5 to 60 |
| Open gripper jaws at gripping force of 6 bar [N] | 967 |
| Close gripper jaws at gripping force at 6 bar [N] | 928 |
| Mass inertia [kg/cm²] | 80,33 |
| Max. force on gripper jaws Fz static [N] | 3.000 |
| Max. torque on gripper jaws Mx static [Nm] | 120 |
| Max. torque on gripper jaws My static [Nm] | 80 |
| Max. torque on gripper jaws Mz static [Nm] | 65 |
| Lubrication interval guide elements [Mio SP] | 5e+006 |
| Max. mass per external griper finger [g] | 1.340 |
| Product weight [g] | 3.365 |
| Fastening type | With Throughway bore and dowel pin<br>With Female thread and dowel pin<br>Selectively:<br>Female thread and centring sleeve<br>With Throughway bore and centring sleeve |
| Pneumatic connection blocking air | M5 |
| Pneumatic connection | G1/8 |
| Material information | RoHs compliant |
| Cover cap material | High-alloyed stainless steels |
| Housing material | aluminium<br>anodized |
| Gripper jaws material | hardened<br>Steel |
| Manufacturer Nr. | HGPD-63-A |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568227197 |
| Weight | 3.500000 |
| HS-Code | 84798997 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
| Temperature (max.) | 60 |
| Material | Aluminium |
| Betriebsdruck max [bar] | 8.000000 |
| Pneumatic connection | G1/8 |
| Protection rating | IP65 |
| Series | HGPD |
| Medium | Compressed air |
| Funktion | double-acting |
| Corrosion resistance class CRC | 2 - moderate corrosion stress |
| Mounting position | arbitrary |
| Design | Inclined plane, Force controlled movement cycle |
| Position sensing | Yes |
