Control Cabinet AM PL EU I3 0.9x0.6 with UPS and i5 Controller - Bosch Rexroth 3842564864

BOSCH REXROTH Original product
Net price (excl. VAT)
€28,429.02
Excl. 19% VAT , excl. Shipping Cost
Available Fast shipping
Item BRR-3842564864
Manufacturer no. 3842564864
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842564864
ConditionNew
Add to Wish List Add to Compare
Article
BRR-3842564864
Control Cabinet AM PL EU I3 0.9x0.6 with UPS and i5 Controller - Bosch Rexroth 3842564864
The product may differ from the illustration
Ready-to-use control cabinet for Bosch Rexroth transfer systems (EU version), fully pre-wired with no internal assembly required. Integrates an i5 controller, uninterruptible power supply (UPS, 24 V / 10 A), and a filter-fan unit for climate control. Supports Stop Category 1 emergency stop per DIN EN 60204-1 and major PLC interfaces including PROFINET, EtherCAT, and Ethernet/IP.
Frequently Bought Together
Total price

The AM PL EU I3 0.9x0.6 control cabinet is the plug-and-play electrical control unit for Bosch Rexroth assembly transport systems in the EU configuration. The painted sheet-steel enclosure (graphite gray RAL 7024) arrives fully wired - no internal cabinet work is needed on site. A built-in filter and fan (filter: PA, RAL 7035) maintain the internal climate. The integrated UPS (24 V DC / 10 A) keeps the system running through brief power interruptions, and the emergency-stop safety circuit meets Stop Category 1 per DIN EN 60204-1.

  • Delivered ready to operate - no internal wiring required
  • UPS 24 V DC / 10 A for continued operation during power interruptions
  • Emergency stop Stop Category 1 per DIN EN 60204-1
  • Flexible PLC connectivity: PROFINET, EtherCAT, Ethernet/IP and further protocols
  • Integrated filter and fan for enclosure climate control

Technical data

SpecificationValue
ColorGraphite gray RAL 7024
Rated frequency50 Hz
Input voltage AC400 V
Output voltage AC230 V
UPS output voltage DC24 V
UPS output current10 A
Line current rating55 A
Mass70 kg (net) / 75 kg (gross)
Housing materialSheet steel, painted
Filter materialPA, RAL 7035
Controlleri5 processor
Cabinet delivery stateNo assembly required, ready to operate
Interface module connecting kitAssembly required on site
Scope of deliveryConnecting kit (ferrites, network cable, cable protection hose, 24 V cable, grounding cable, network coupler, fastening kit), circuit diagram, i5 controller, UPS, all necessary electrical components
Required accessoriesInterface module (PROFINET / EtherCAT / Ethernet/IP), control cabinet connecting kit
Recommended accessoriesConnecting cable for line, PLC, AMpro
More Information
Manufacturer Nr. 3842564864
Manufacturer Bosch Rexroth
Weight 0.100000
GPSR manufacturer information Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Article authenticity Original product
Condition of article New
