Belt Section BS 2/R-V+ 1200 with Accumulating Roller Chain, ESD-Compatible - Bosch Rexroth 3842998492
Datasheet (PDF)
The product may differ from the illustration
The BS 2/R-V+ 1200 belt section is a ready-to-install conveyor unit with its own drive for transporting workpiece carriers longitudinally or, combined with two HQ 2 lift-and-transfer units, laterally between parallel lines. The Vplus accumulating roller chain is EPA-rated (ESD-safe), supports a maximum accumulation load of 1200 kg, and accommodates track widths from 400 to 1200 mm and lengths from 650 to 6000 mm.

Belt Section BS 2/R-V+ 1200 with Accumulating Roller Chain, ESD-Compatible - Bosch Rexroth 3842998492

BOSCH REXROTH Original product
Net price (excl. VAT)
€4,227.61
Excl. 19% VAT , excl. Shipping Cost
Available Fast shipping
Item BRR-3842998492
Manufacturer no. 3842998492
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842998492
Country of originGermany
Customs tariff number84313900
ConditionNew
Add to Wish List Add to Compare
Article
BRR-3842998492

The BS 2/R-V+ 1200 belt section from Bosch Rexroth is a self-contained conveyor unit for the TS 2plus transfer system. It moves workpiece carriers in the longitudinal direction or - paired with two HQ 2 lift-and-transfer units - across to a parallel line. The Vplus accumulating roller chain is qualified for use in electrostatic protected areas (EPA/ESD), and workpiece carriers on it can reach speeds up to 2.5 times the chain speed. For chain speeds above 9 m/min, specific dimensional constraints apply.

  • ESD-compatible: Vplus accumulating roller chain approved for EPA environments
  • Maximum accumulation load: 1200 kg
  • Track width (b): 400-1200 mm; length (l): 650-6000 mm - scalable to line requirements
  • Motor mounting: right, left, or centre; connection via cable/plug or terminal box
  • Reversing operation available for l ≤ 2000 mm with chains without small-parts guard
  • Nominal speeds: 0, 6, 9, 12, 15, or 18 m/min (vN = 0: supplied without motor and gearbox)
  • Energy-efficient design per Rexroth 4EE

Technical data

ParameterValue
Article number3842998492
ProductBelt section BS 2/R-V+ 1200
Conveying mediumVplus accumulating roller chain (EPA-rated)
Max. accumulation load1200 kg
ESD-compatibleyes
Track width b400-1200 mm
Length l650-6000 mm
Nominal speed vN0 / 6 / 9 / 12 / 15 / 18 m/min
Motor mountingright (R), left (L), centre (M)
Motor connectioncable/plug (S) or terminal box (K)
Reversing operationavailable for l ≤ 2000 mm, chains without small-parts guard
Chain type (KT)KT 2: steel rollers; KT 4: steel rollers with small-parts guard
Slide profilesteel, corrosion-resistant
Small-parts guardsteel
Weight0.0099 kg (order unit/accessory)
More Information
Execution TEC
Manufacturer Nr. 3842998492
Manufacturer Bosch Rexroth
Country of Manufacture Germany
Weight 0.009900
HS-Code 84313900
GPSR manufacturer information Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Article authenticity Original product
Condition of article New
