USB Handheld Microscope 1.3 MP 5-40x Long Working Distance - Dino-Lite AM4113TL-M40

Wide field at a long working distance

The AM4113TL-M40 is built for inspections where clearance between optic and object matters, such as boards held in a fixture, recessed cavities or thermally sensitive assemblies. The long working distance gives a continuous 5x to 40x overview rather than a narrow frame pressed against the surface.

Key features

• 5x to 40x magnification with long working distance for an unobstructed view of larger areas
• 1.3 MP sensor at 1280 x 1024 pixels and up to 30 frames per second for a steady live image
• MicroTouch trigger to capture directly at the device without shake
• Measurement and calibration through DinoCapture and DinoXcope
• Eight white LEDs for even illumination across the working field

Technical data

• Sensor: 1.3 MP, 1280 x 1024
• Magnification: 5x to 40x (maximum 40x)
• Working distance: long (LWD)
• Interface: USB 2.0
• Illumination: 8 white LEDs
• Polarizer: no
• Weight: approx. 0.11 kg

Applications

• Electronics and PCB inspection in fixtures
• Checking recessed or hard-to-reach features
• Incoming goods and quality control with on-screen measurement

Compatibility and contents

Works with Dino-Lite MS and RK series stands and with the BL-CDW and BL-ZW1 backlights. DinoCapture (Windows) and DinoXcope (Mac) software included.

Standards and origin

Made in Taiwan by AnMo Electronics. Customs code 90118000.
