USB foot pedal for hands-free image capture - Dino-Lite SW-F1
The Dino-Lite SW-F1 USB foot pedal triggers image capture with your foot, so both hands stay on the object and the microscope. According to the manufacturer it works with all Dino-Lite and Dino-Eye USB models running DinoCapture 2.0 (Windows) or DinoXcope (Mac), not with wireless models.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Holding the object with one hand and adjusting focus with the other leaves no hand free for the shutter. The Dino-Lite SW-F1 moves image capture to your foot. One press on the pedal takes the picture.
The pedal plugs into a USB port on the computer and is ready to use. It works with DinoCapture 2.0 on Windows and DinoXcope on the Mac, no further software is needed. The manufacturer approves it for Dino-Lite USB microscopes and Dino-Eye USB eyepiece cameras.
What it does in practice
- Both hands stay on the workpiece while soldering, inspecting or aligning. No reaching for the mouse to take a picture.
- Image series go faster because you no longer switch between workpiece and keyboard.
- At 10 x 7 x 3 cm the pedal takes up little room under the bench.
Works with
Microscopes: according to the manufacturer, all Dino-Lite USB models and Dino-Eye USB eyepiece cameras, as long as they run on a computer with DinoCapture 2.0 or DinoXcope. Examples from our range are the AM4115ZT, AM4815ZT, AM7115MZT, AM73915MZT and the AM4025X and AM7025X eyepiece cameras.
Not suitable: wireless models and operation over Wi-Fi, for example the WF4115ZT or WF7515MZT wireless sets.
Technical data
| Property | Value |
|---|---|
| Type | USB foot pedal for image capture |
| Connection | USB, plug and play |
| Software | DinoCapture 2.0 (Windows), DinoXcope (Mac) |
| Dimensions | 10 x 7 x 3 cm (W x L x H) |
| Weight | 300 g |
| ESD safe | No |
| Warranty | 2 years manufacturer warranty |
| Package contents | 1 foot pedal |
| Manufacturer | Dino-Lite |
| Manufacturer Nr. | SW-F1 |
| EAN | 4712805471515 |
| HS-Code | 90119090 |
| GPSR manufacturer information | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment, info@esd.equipment |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Taiwan |
| ESD version | TEC |
| ESD equipment | USB Mikroskop |
| Interface | USB 2.0 |
Downloads
Datasheet
User Manual
Brochure
