HR100A Hybrid Rework System, IR + Hot Air, 200 W - Ersa 0IRHR100A

The HR100A is a microprocessor-controlled hand-held rework system for BGA and SMT applications on small, high-pin-count components. Using hybrid technology, it combines IR radiation with hot air, and both the air flow and the IR power can be adjusted continuously and independently.

Features

• Hybrid technology: combined use of IR radiation and hot air
• Air flow and IR power continuously and independently adjustable
• 200 watts combined IR and air heating power
• Three hybrid adapters with optimised process parameters for different component sizes
• Integrated VacPen vacuum gripper for handling electronic components
• Closed-loop temperature control with contactless temperature measurement or external AccuTC thermocouple to run a profile with ramp and maximum temperature
• Expandable to a stationary system with bottom heating and stand via the optional IRHP100A heating plate
• Process control, documentation and archiving of processes via the optional IRSoft software

Scope of supply

• Hybrid Tool heating element and VacPen vacuum pipette
• Three hybrid adapters 6 x 6 mm, 10 x 10 mm and 20 x 20 mm
• Fume extractor (without stand)
