Assembly Technology Bosch Rexroth - ESD (antistatic)

ESD Workplaces

Bosch Rexroth assembly technology combines aluminium profile systems, transfer systems, and manual production workstations into a fully configurable assembly ecosystem. The mechanical base elements use the groove-10 strut profile in grid dimensions R40 and R45, assembled with connectors, brackets, and accessories into frames, material carts, and shelving systems. Chain conveyor systems such as VarioFlow+ (28 VDC, aluminium) and transfer systems TS 2plus/TS 5 with rotary units, lift units, and AC BASIS software extend the applications towards semi-automated assembly lines.

For workpiece carrier and assembly identification, RFID systems of the ID15 and ID200 series are available, integrable via AS-Interface or Ethernet into PLC control systems. The accessories range of more than 300 articles covers sensors, high-pressure hoses, chain links, positioning units, and connection sets for all systems. Grab bins in standard and ESD versions (GB series, sizes 0805 to 1710) supplement the offering for parts presentation at assembly workstations.

Categories

Mechanical Base Elements Bosch RexrothStrut profiles groove 10, R40/R45, connectors and brackets

Transfer Systems Bosch RexrothTS 2plus, TS 5, rotary units DE 2, lift unit EL 2

Manual Production Systems Bosch RexrothWorkbench frames, cabinet systems, shelves, work chairs

Chain conveyor system Bosch Rexroth VarioFlow+

Chain Conveyor System VarioFlow+28 VDC, modular aluminium segments, curved extensions available

RFID Systems Bosch RexrothID15 AS-I, ID200 ETH/PDP, data carriers, antennas, mounting sets

Grab Bins Bosch RexrothGB series 0805-1710, standard and ESD, with covers and grips

Accessories Bosch RexrothSensors, connection cables, chain links, positioning units

⚙ Profile system groove 10, R40/R45 - universal connector technology, strut profiles for assembly frames

⚡ VarioFlow+ 28 VDC - modular aluminium chain conveyor, extendable with curved segments

📦 RFID ID15/ID200 - AS-Interface and Ethernet connection, MDT-series data carriers

✦ Grab bins GB series ESD - sizes 0805 to 1710, with transparent covers

✓ Transfer systems TS 2plus/TS 5 - rotary units DE 2 (BG 1-5), lift unit EL 2, AC BASIS software

System	Application	Key specification
Mechanical base elements	Modular assembly frames	Groove 10, R40/R45
VarioFlow+	Chain conveyor system	28 VDC, aluminium, curved segments
TS 2plus / TS 5	Transfer systems	DE 2 BG 1-5, EL 2, AC BASIS
RFID ID15	Identification, AS-Interface	Reader, programmer, connection cables
RFID ID200	Identification, Ethernet/PROFIBUS	Communication module ETH/PDP, antennas
Grab bins GB	Parts presentation	0805-1710, standard and ESD

Typical applications: Manual assembly lines in the automotive and electronics industries, semi-automated transfer lines with TS 2plus/TS 5 and VarioFlow+, RFID-based workpiece carrier tracking in series production, ESD-protected assembly workstations for the electronics industry, and parts presentation systems with grab bins in lean manufacturing environments.

✓ Authorised distributorBosch Rexroth assembly technology from stock

📦 336+ accessory articlesSensors, connections, chains, positioning units
