Anodized aluminium cable duct (80x80 mm, usable length 3000 mm) for organised cable routing at assembly workstations and profile-frame systems. ESD-conductive, VDE-certified to DIN EN 50085, supplied pre-assembled with screwable cover and integrated edge protection. Delivery unit: 6 pieces.
ESD Cable Duct with Aluminium Cover 80x80, 3000 mm, Pack of 6 - Bosch Rexroth 3842552275
BOSCH REXROTH
Original product
Net price (excl. VAT)
€733.16
Item
BRR-3842552275
Manufacturer no.
3842552275
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.3842552275
Country of originSweden
Customs tariff number76042100
ConditionNew
Article
BRR-3842552275
Frequently Bought Together
-
This Item:
€733.16
-
Cable Duct with Aluminium Cover 40x80, ESD-Conductive, 3000 mm, Pack of 12 - Bosch Rexroth 3842552270
€1,115.00
-
Cable Duct PVC 34x20 mm, L=2000 mm, Signal Grey - Bosch Rexroth 3842559336
€25.13
Total price
The Bosch Rexroth 80x80 mm cable duct provides structured routing for multiple cable types at assembly workstations and profile-frame installations. The anodized aluminium finish protects against corrosion and delivers a consistent appearance on both the duct body and cover plate. The interior is divisible into 80x40 and 80x80 configurations, allowing different cable groups to be separated within a single duct. ESD conductivity and VDE certification make it suitable for electrostatically sensitive production areas.
- ESD-conductive - reliable dissipation of electrostatic charges in sensitive environments
- Anodized aluminium body and cover - durable corrosion resistance and uniform finish
- Divisible interior - separate different cable types in 80x40 or 80x80 configuration
- Integrated edge protection - prevents damage to cables and conductors at cut edges
- Screwable cover with self-tapping screw 3842552267 - conductive connection and secure fixing
- PG cable glands, sockets and switches can be fitted by mechanical machining
- VDE-certified, compliant with DIN EN 50085-1 and DIN EN 50085-2-1
- Supplied pre-assembled (cover and base), usable length 3000 mm, delivered length 3100 mm
Technical data
| Specification | Value |
|---|---|
| Article number | 3842552275 |
| Dimensions (W x H) | 80 x 80 mm |
| Usable length | 3000 mm |
| Delivered length | 3100 mm |
| Material | Aluminium, anodized |
| Profile slot | 10 |
| ESD-conductive | yes |
| Standard | DIN EN 50085-1, DIN EN 50085-2-1 |
| Certification | VDE |
| Weight | 42 kg |
| Delivery unit | 6 pieces |
| Recommended accessory | Self-tapping screw 3842552267 |
| Weight | 42.000000 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Manufacturer Nr. | 3842552275 |
| HS-Code | 76042100 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Sweden |
| Lenght | 3000 mm |
| ESD version | ESD (antistatic) |
| Norm | DIN EN 50085, DIN EN 50085-1, DIN EN 50085-2-1 |
