USB Digital Microscope 5 MP 10-220x with EDOF and Polarizer - Dino-Lite AM7915MZT

5 MP microscope with extended depth of field

The Dino-Lite AM7915MZT is built for inspecting objects with height differences where a single focus plane is not enough. Extended Depth of Field (EDOF) merges several focus planes into one fully sharp image, while the polarizer and 5 megapixel resolution deliver clear, high-contrast captures at 10-220x.

Key benefits

• 5 megapixel sensor with 10-220x optical magnification for detailed capture.
• Extended Depth of Field (EDOF) for fully sharp images of uneven surfaces.
• Extended Dynamic Range (EDR) reduces glare on shiny areas.
• Built-in, continuously adjustable polarizer for reflection control.
• Automatic Magnification Readout (AMR) and Flexible LED Control (FLC) for measurement and directional lighting.

Technical specifications

• Sensor: 5 megapixel
• Magnification: 10-220x
• Interface: USB 2.0
• Illumination: 8 white LEDs with FLC
• Polarizer: integrated, adjustable
• Housing: aluminium
• Functions: EDOF, EDR, AMR, measurement, calibration, exchangeable front caps (N3)

Applications

Inspection of PCBs and solder joints with height differences, examination of three-dimensional components, material and surface analysis, and documentation in research and development.

Compatibility

The Edge front cap system (N3) allows ESD-safe caps, a ring light or coaxial light. MS and RK series stands and the foot switch provide repeatable captures.

Standards and origin

Made in Taiwan. Supplied with DinoCapture 2.0 software.
