VGA Microscope 800x600 10-90x Polarizer and Long Working Distance - Dino-Lite AM4116ZTL

Real-time inspection directly on a monitor

The AM4116ZTL sends the image through a VGA connection at 800 x 600 directly to a monitor and works without a computer. At up to 60 frames per second it delivers a smooth live image. The adjustable polarizer suppresses reflections, and the long working distance of up to around 16 cm leaves room for tools.

Key features

• VGA output 800 x 600 for a direct monitor connection without a computer
• Real-time image at up to 60 frames per second
• Adjustable polarizer, full or half, against glare on shiny surfaces
• 10x to 90x magnification with a long working distance up to approx. 16 cm
• Eight white LEDs, switchable

Technical data

• Output: VGA (D-Sub) 800 x 600
• Magnification: 10x to 90x (maximum 90x)
• Working distance: long, up to approx. 16 cm
• Frame rate: up to 60 frames per second
• Illumination: 8 white LEDs, switchable
• Polarizer: yes, adjustable
• Weight: approx. 0.12 kg

Applications

• Live inspection at workstations without a computer
• Production and quality control with direct monitor display
• Inspection of shiny surfaces with glare suppression

Compatibility and contents

Works with Dino-Lite MS-W1, RK-02 and MS08B stands. DinoCapture and DinoXcope software are intended for the USB models of the series, while this model outputs the image directly through VGA.

Standards and origin

Made in Taiwan by AnMo Electronics. Customs code 90118000.
