Ring light front cap for Edge microscopes - Dino-Lite N3C-R
The Dino-Lite N3C-R ring light cap redirects the microscope's built-in LEDs into an even, shadow-free ring light, with no external power needed. According to the manufacturer it fits the Edge models AM4115, AM4515, AM4815, AM7115, AM7515 and AM7915, but not high magnification or extra long working distance models. Best working distance 2 to 15 cm.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
In macro work a ring light takes the shadows out of the image and brings out surface detail. The Dino-Lite N3C-R produces one without an extra lamp: the clip-on cap, 6.5 cm in diameter, redirects the microscope's built-in LEDs into a focused, diffused and uniform ring of light.
Since no external ring light has to be mounted or powered, there is no added heat, and at 8 g the cap adds hardly any weight. It works best at a working distance of 2 to 15 cm. The manufacturer does not recommend it for shorter distances.
What it does in practice
- Shadow-free lighting for macro images, without cables or a power supply for an extra lamp.
- On polarizer models such as the AM4115ZT, AM4515ZT or AM7515MZT the polarizer still works and cuts glare and reflections.
- The cap clips onto the front mount and swaps quickly with the standard cap.
Works with
Microscopes: according to the manufacturer, the Edge USB models AM4115, AM4515, AM4815, AM7115, AM7515 and AM7915, except high magnification and extra long working distance models. Examples: AM4115T, AM4115ZT, AM4515ZT, AM4815ZT, AM7115MZT, AM7515MZT and AM7915MZT.
Not suitable: high magnification models such as the AM4515T5, AM4515T8, AM4515ZT4 and AM7515MT8A, and the extra long working distance models AM4115TF, AM7115MTF, AM73115MTF, AM5216TF and AM5218MZTF. The cap is also not meant for work at short working distances.
Technical data
| Property | Value |
|---|---|
| Type | Passive ring light cap, redirects the built-in LEDs |
| Dimensions | 1.55 cm (H) x 6.5 cm (D) |
| Weight | 8 g |
| Recommended working distance | 2 to 15 cm |
| Material | ABS plastic |
| ESD safe | No |
| Regulatory approval | RoHS |
| Warranty | 2 years manufacturer warranty |
| Package contents | N3C-R ring light cap |
| Manufacturer | Dino-Lite |
| Manufacturer Nr. | N3C-R |
| EAN | 4712805475414 |
| HS-Code | 90119090 |
| GPSR manufacturer information | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment, info@esd.equipment |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Taiwan |
| ESD version | TEC |
| ESD equipment | USB Mikroskop |
