Festo AEVC-16-10-I-P (188100) Short-Stroke Cylinder
€48.05
Excl. 19% VAT , excl. Shipping Cost
Article
FES-188100
Manufacturer Nr.
AEVC-16-10-I-P
Short-Stroke Cylinder
Frequently Bought Together
- This Item: €48.05Excl. 19% VAT , excl. Shipping Cost
- Festo AEVC-12-10-A-P-A (188085) Short-Stroke Cylinder €50.28Excl. 19% VAT , excl. Shipping Cost
- Festo AEVC-20-25-I-P (188133) Short-Stroke Cylinder €54.31Excl. 19% VAT , excl. Shipping Cost
Total price
| Stroke [mm] | 10,0 |
| Piston diameter | 16 mm |
| Spring return force for retracted piston rod [N] | 5 |
| Dampening | P: Elastic silencer rings / plates double-sided |
| installation position | arbitrary |
| Principle of operation | Pressing single action |
| Construction set up | Piston piston rod |
| Position detection | without |
| Operating pressure [bar] | 1.5 to 10 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Corrosion resistant class KBK | 1 - low corrosion stress |
| ambient temperature [°C] | -20 to 80 |
| Theoretical force at 6 bar, flow [N] | 112,0 |
| Moving mass [g] | 11,00 |
| Product weight [g] | 80,0 |
| Fastening type | With throughway bores With Accessories Selectively: |
| Pneumatic connection | M5 |
| Material information | Copper and PTFE-free |
| Cover material | Aluminium wrought alloy anodized |
| Seals material | NBR TPE-U(PU) |
| Housing material | Aluminium wrought alloy anodized |
| Piston rod material | High-alloyed steel |
| Manufacturer Nr. | AEVC-16-10-I-P |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568076887 |
| Weight | 0.048000 |
| HS-Code | 84123100 |
