Bernstein 5-452. ESD changeable ceramic tweezers tips 2.0 width, dissipative
ESD changeable ceramic tweezers tips 2.0 width, dissipative
- This Item: €49.57Excl. 19% VAT , excl. Shipping Cost
- Bernstein 5-079-13. ESD cutting tweezers 115 mm form 15 AGW stainless steel, dissipative, oblique €24.13Excl. 19% VAT , excl. Shipping Cost
- Bernstein 9-341-2. ESD spiral cord for bracelet length 2.4 m yellow €6.11Excl. 19% VAT , excl. Shipping Cost
- rounded tips width 2.0 mm
- form 2AZJ
- material tip ceramic/zirconia
- matt polished surface, smooth and glare-free
- conductive between 10^6 - 10^9 ohms
- length 125 mm
- weight 17 g
Special tweezers with replaceable ESD ceramic (ZIRCONIA) tips for very sensitive components.
Zirconium oxide is a highly wear-resistant, tetragonal ZrO2, Y2O3 partially stabilized. Physical properties at room temperature: flexural strength 800N/mm², modulus of elasticity 2x105N/mm², density 6.05g/cm³, hardness 1350HV, application range up to 800°C, coefficient of thermal expansion 10x10-6 K-1, thermal conductivity 2W/mK, electrical resistance 10^8 Ohm. In addition, it is solder-repellent, heat-resistant and resistant to acids and alkalis. ESD ceramic tips meet the highest requirements due to their excellent mechanical, thermal and electrical properties, dissipative between 10^6 and 10^9 Ohm and long service life. The tweezer body is made of high quality stainless steel and is antimagnetic and acid resistant.
| Execution | ESD (antistatic) |
|---|---|
| Manufacturer Nr. | 5-452 |
| Manufacturer | Bernstein |
| EAN | 4250838512350 |
| Weight | 0.017000 |
| Lenght | 125 |
| HS-Code | 82032000 |
