€649.05
Excl. 19% VAT , excl. Shipping Cost
Article
BS-9-155
Manufacturer Nr.
9-155
Stereo-Microscope with table stand
Frequently Bought Together
- This Item: €649.05Excl. 19% VAT , excl. Shipping Cost
- Bernstein 9-342. ESD contact bracelet with spiral cord and crcodile clip €23.85Excl. 19% VAT , excl. Shipping Cost
- Bernstein 9-354-100. ESD topping 500x400x0,5 mm €11.84Excl. 19% VAT , excl. Shipping Cost
Total price
- stereo head 45° oblique view, 360° rotatable adjustable eye distance of 54 - 74 mm
- table stand 200 x 150 mm
- magnification 10 x / 20 x expandable by attachable lenses up to 40 x
- eyepieces wide field 10 x ocular tube left with diopter adjustment of + - 5 dpt, eyepiece cup
- weight 5300 g
Area of application
The microscopes are particularly suitable for reliable checks of material and assembly details as well as the finest work in SMD technology.
PDF
Technical description
Stereo microscope with stable metal tripod for incident light illumination. The column length of 245 mm allows a working distance of 83 mm at 10 x / 20 x magnifications. The field of view at a magnification of 10 x is 19 mm in diameter. The LED ring illumination has a bright, shadow-free incident light with a light colour of 5800 K. The light is illuminated by a LED ring. The brightness is continuously adjustable between 0 and 15000 lux.
Execution | TEC |
---|---|
Manufacturer Nr. | 9-155 |
Manufacturer | Bernstein |
EAN | 4250838511001 |
Weight | 5.300000 |
HS-Code | 90111000 |
