ESD contact bracelet with spiral cord and crcodile clip
- This Item: €23.85Excl. 19% VAT , excl. Shipping Cost
- Bernstein 9-354. ESD handling set 5 pcs (500x400x0.35 mm) €63.97Excl. 19% VAT , excl. Shipping Cost
- Bernstein 7-421. ESD brush bristles 6 mm €12.63Excl. 19% VAT , excl. Shipping Cost
- LGA tested BGI 818 (ZH1 / 267). Meets the safety requirements for wrist grounding according to BGFE GERMAN Standard.
- adjustable, anti-allergic, washable
- belt length 220 mm
- press buttons 3-4 mm for wrist strap and 10 mm for ground contact connection
- highly elastic 2400 mm long spiral cable
- 2 x 1 megohms safety resistor
- additionally insulated crocodile clip for grounding with clamp connection
- color dark blue
- weight 60 g
Wrist grounding, as a safe method to derive electrostatic charge from people, consists of an adjustable wrist strap with woven silver-plated synthetic fibers (close skin contact necessary) and a spiral cable, which connects the wristband with the earthing point via press-studs, electrically dissipative. The coiled cable has a safety resistance of 1 MOhm on each connection side and is approved for workplaces with a rated voltage up to 250 VAC. To ensure adequate insulation, the bracelet may only be stored in a dry place.
Washing instructions for the bracelet: machine wash up to 30 ° C with soft washing powder, drying at low temperature (warm not hot), do not bleach (!) avoid contact with acidic / alkaline solvents. ESD protection is retained for about 30 washing process.
Execution | ESD (antistatic) |
---|---|
Manufacturer Nr. | 9-342 |
Manufacturer | Bernstein |
EAN | 4250838511599 |
Weight | 0.060000 |
HS-Code | 39269097 |
