€1,168.83
Excl. 19% VAT , excl. Shipping Cost
Article
EarScope Pneumatic
Manufacturer Nr.
EarScope Pneumatic
The pneumatic EarScope (MEDL4EP) is a compact and safe solution for watching the eardrum and the external ear. The MEDL4EP has a 1,3 Megapixel resolution and a magnification of 55 ~ 90x. It comes with a rubber bulb that is squeezed to give a puff of air into the ear canal, which allows the doctor to see how the eardrum moves. This model is delivered with disposable specula of 2,5 and 4 mm (10 each). EarScope Product Brochure
Frequently Bought Together
- This Item: €1,168.83Excl. 19% VAT , excl. Shipping Cost
- Dino-Lite AM7115MZTL €929.00Excl. 19% VAT , excl. Shipping Cost
- Dino-Lite SW-F1 €57.50Excl. 19% VAT , excl. Shipping Cost
Total price
Additional Info
Dino-Lite medical range: | Dino-Lite EarScope |
---|---|
Article code: | MEDL4EP |
Lighting
Light/ LED type: | White |
---|---|
Number of LEDs: | 6 |
LED on/off switchable: | Yes |
Infrared filter: | IR cut-filter >650 nm |
Diffuser available: | No |
Polarizer: | No |
Optics
Magnification: | 55-90x |
---|---|
Lens type: | Glass with Anti-Reflection coating |
Sensor
Sensor type: | CMOS |
---|---|
Resolution: | 1.3 Megapixel (1280x1024) |
Maximum frame rate: | 30 fps |
Compatibility
Interface: | USB 2.0 |
---|---|
Operating system: | Windows XP, Vista, 7, 8 & 10, MacOS 10.4 and up |
Included software: | DinoCapture 2.0 (Windows), DinoXcope (Mac OS) |
Supported image formats (Windows): | BMP, GIF, PNG, JPG, TIF, RAS, PNM, TGA, PCX, MNG, WBMP, JP2, JPC, PGX |
Supported video formats (Windows): | WMV, FLV, SWF |
Supported image formats (MacOS): | JPEG, PNG |
Supported video formats (MacOS): | MOV |
Imaging standards: | DirectShow, UVC |
Housing
Housing material: | Composite/plastic housing |
---|---|
Magnification lock: | Yes |
Dimensions: | 10.5 cm (L) x 3.2 cm (D) |
Weight: | 95 g |
Cable length: | 1.8 m |
Features
Measurement: | Yes |
---|---|
Calibration: | Yes |
Microtouch sensor: | Yes |
Information
Package contents: |
| |
---|---|---|
Warranty information: | 2 years European warranty | |
Regulatory approval: | Medical Device Class 1 – According to Directive 93/42/EEC modified 2007/47/EC | |
Price range: | €300,00 - €500,00 |
Execution | TEC |
---|---|
Manufacturer Nr. | EarScope Pneumatic |
Manufacturer | Dino-Lite |
Country of Manufacture | Taiwan, Province of China |
Weight | 0.095000 |
HS-Code | 90119090 |
