Inline-Luftfilter 3er-Pack 0,1µm 99,99% Effizienz – Iteco 9265532

9265.530

9265.532
9265.520
9265.523
9265.542
9265.544
FREE AIR
VALVE OR
SHUT OFF
9265.523
9265.520
9265.530
IONIZING GUNS
Usable also in clean room, ergonomically designed, light, it is used to blow off charged
dust particles from electronic cards and other equipment or materials. Extremely light,
anatomic, and with a flexible soft cable (no HIGH voltage passing through this cable)
6115 LIGHT ANATOMIC GUN
HEAVY DUTY TOP GUN
6110A AIR CARTRIDGE
Ionizing guns neutralize static charges and clean surfaces using compressed air that is ionized. Like all the ionizers they fi nd ap-
plication in the electronic industry, but they can be useful in many other contest like mechanical industry, painting works, packing
areas, displays cover removing, etc… This because the neutralization of static charges simplifi es the cleaning works and prevents
the risk that airborne particles and dust will be attracted again.
The cartridge can be used either for in-line ionization or as ionizing blow-
off gun, adapts to compressed air lines. Two models available, one turns
off ionizer when air is not flowing.
Weight: 170g
Power:: 24Vac, 1W, from 9265.544 wall transformer
Designed for heavy duty jobs, due to its high performance, reliability and
durability.
There is a flow control valve to adjust airflows for the specifi c application.
It is completely ESD and can be used even in clean rooms.
The version with sidekick allows “hands free” operation.
Discharge time: from 1000 to 100V ≤ 0.5seconds at 5cm at 60 psi
Air Input: adjustable to 100 psi (7 bar) max.
Power requirement: 230Vac
Noise: 76 dBA at 60cm, 30 psi
Gun ergonomic, low-noise, weight 0.34kg
Discharge time: from 1000 to 100V ≤ 0.5seconds at 6”, 30psi
Emitter points: Machined Titanium, fi eld-replaceable
Gas input: 20-87psi(1.4-6 bar), Clean dry air or Nitrogen
Ozone: 0.005ppm (24 hour accumulation)
Noise: 70dbA at 1m, 30psi
Power: requirement 24Vac - 10W
Complete kit including hand unit, console,
air fi lter and transformer 220/24Vac
Additional Filter pack,(Pack of 3) - 0.1mm 99,99%EFF
Ionizing Gun TOP-GUN, 230Vac
Ionizing Gun TOP-GUN, 230Vac
with flexible support and Sidekick (foot pedal switch)
ATTENTION: the cartridge don't withstand high
air pressure. It should be installed downstream from
any system valves or shutoffs
Ionizing cartridge, air flow triggered - 24Vac
Transformer 230/24Vac
69
