Bosch Rexroth 3842546070. Flat conveyor chain VFplus 90

Flat conveyor chain VFplus 90

• The flat conveyor chain is used to transport products directly or indirectly via workpiece pallets
• The gray conveyor chain is mainly used to transport products indirectly via workpiece pallets, in particular for steel wear pads. The dark coloring means that there is virtually no visual impairment of the chain surface
• Transport on ascending or descending sections up to about 7° possible, depending on the product (test required)
• Accumulation operation permitted, depending on the product
• From size 160: Chain plate easy to replace
• Size gray chain: 65, 90
• Chain links can be combined with other types of chains of the same size
• Chain also available in version ESD, see conveyor chain ESD
• Drilling the flat chain links allows for the simple attachment of customer-specific superstructures. Sizes 65-120 have a mold cavity for accommodating a flat M5 hexagon nut. Sizes 160-320 have a centering aid mounted on the underside of the chain plate. Max. drilling up to Ø5 mm, since at this point there are no interfering contours in the chain conveyor
• Extremely quiet chain running thanks to the patented chain design
