€971.09
Excl. 19% VAT , excl. Shipping Cost
Article
BRR-3842998517
Manufacturer Nr.
3842998517
VE 5/D-300 stop gate
Frequently Bought Together
- This Item: €971.09Excl. 19% VAT , excl. Shipping Cost
- Bosch Rexroth 3842545134. Assembly kit for SH 2/U-H on ST 5/H, ST 5/XH €43.96Excl. 19% VAT , excl. Shipping Cost
- Bosch Rexroth 3842545616. Protective cover for ST 5/XH, ST 5/H b=455 p2/p3=130/195 €188.81Excl. 19% VAT , excl. Shipping Cost
Total price
VE 5/D-300 stop gate
- Damped stopping of one or more accumulating workpiece pallets at the defined Workpiece pallet stop surfaces.
- Pneumatic stop gate with steplessly adjustable damping. When the pressure is released the stop gate is closed by a spring and the Workpiece pallet is stopped.
- Compressed air connection: 5 ... 6 bar
- Pneumatic connection, pushlock Ø 6 mm
Pneumatic straight connection [] [mm] | 6 |
required compressed air connection [pmin] [bar] | 5 |
Preferred values [mm] | 455,650,845,1040 |
Nominal speed [m/min] | 9,12,18 |
Scope of delivery | Incl. fastening material for installation on conveyor section, Push in air connection 6 mm |
Workpiece pallet total weight [mG] mult [kg] | 300,260,160 |
Delivery information | Not assembled |
required compressed air connection [pmax] [bar] | 6 |
Recommended accessories | 3x sensors 3 842 549 811 or 3 842 549 814 for stop gate position inquiry engaged, top position- stop gate position inquiry not engaged, bottom position- position inquiry damper handle retracted: yes/no- clamping holder for sensor |
Weight [kg] | 0 |
Execution | TEC |
---|---|
Manufacturer Nr. | 3842998517 |
Manufacturer | Bosch Rexroth |
Country of Manufacture | Germany |
Weight | 0.009900 |
HS-Code | 84313900 |
