€1,257.02
Excl. 19% VAT , excl. Shipping Cost
Article
BRR-3842998805
Manufacturer Nr.
3842998805
VE 5/D-1000 stop gate
Frequently Bought Together
- This Item: €1,257.02Excl. 19% VAT , excl. Shipping Cost
- Bosch Rexroth 3842545541. Protective covers for ST 5/OC p=130 €175.34Excl. 19% VAT , excl. Shipping Cost
- Bosch Rexroth 3842545639. Protective cover for ST 5/XH-FR, ST 5/H-FR b=1040 p2/p3=130/195 €202.31Excl. 19% VAT , excl. Shipping Cost
Total price
VE 5/D-1000 stop gate
- Oil-damped stopping of one or more accumulating workpiece pallets at the defined Workpiece pallet stop surface.
- Pneumatic stop gate. When the pressure is released the stop gate is closed by a spring and the Workpiece pallet is stopped.
- Compressed air connection: 5 ... 6 bar
- Pneumatic connection, pushlock Ø 6 mm
Pneumatic straight connection [] [mm] | 6 |
required compressed air connection [pmin] [bar] | 5 |
Mass [m] | 50 |
Nominal speed [m/min] | 9,12,18 |
Scope of delivery | Incl. fastening material for installation on conveyor section, Push in air connection 6 mm |
Workpiece pallet total weight [mG] mult [kg] | 1000,900,700 |
Delivery information | Not assembled |
Track width [b] [mm] | 455,650,845,1040 |
required compressed air connection [pmax] [bar] | 6 |
Recommended accessories | 2x or 3x sensors 3 842 549 811 or 3 842 549 814 for - Stop gate position inquiry engaged, top position - Stop gate position inquiry not engaged, bottom position- Damper position inquiry latch retracted: yes/no, only possible if la |
Weight [kg] | 0 |
Execution | TEC |
---|---|
Manufacturer Nr. | 3842998805 |
Manufacturer | Bosch Rexroth |
Country of Manufacture | Germany |
Weight | 0.009900 |
HS-Code | 84313900 |
