Lead time
1 week
€618.93
Excl. 19% VAT , excl. Shipping Cost
Article
AM5216ZT
Manufacturer Nr.
AM5216ZT
The Dino-Lite AM5216ZT connects directly to a VGA screen via a VGA (D-SUB) connector. It offers a high frame rate of up to 60fps at 1280x720 resolution, resulting in crystal clear images. The AM5216ZT is the ideal choice in situations, where real time images are vital, such as working on PCB's or other miniature objects. By tapping the Microtouch sensor on the microscope, the image can be frozen for inspection of important details and by pressing the Microtouch sensor for 2 seconds the LEDs can be switched on and off. The built-in adjustable polarizer reduces glare and reflection on shiny objects, such as metal surfaces, electronics, plastics etc. (The AM5216ZT replaces model AM5116ZT.) » Also available: AM5216T without polarizer
Frequently Bought Together
- This Item: €618.93Excl. 19% VAT , excl. Shipping Cost
- Dino-Lite EarScope Pro €1,168.83Excl. 19% VAT , excl. Shipping Cost
- Dino-Lite AM4023X €409.00Excl. 19% VAT , excl. Shipping Cost
Total price
Additional Info
Dino-Lite range: | Dino-Lite High Speed |
---|
Lighting
Light/ LED type: | White |
---|---|
Number of LEDs: | 8 |
LED on/off switchable: | Yes |
Infrared filter: | IR cut-filter >650 nm |
Diffuser available: | MSAA111A2 (optional accessory) |
Emission filter: | No |
Polarizer: | Yes, linear |
Optics
Magnification: | 20-220x |
---|---|
Macro zoom: | No |
Working distance: | Standard |
Lens type: | Glass with anti-reflection coating |
Sensor
Sensor type: | CMOS |
---|---|
Resolution: | 1280x720 (720p) |
Maximum frame rate: | 60 fps |
Compatibility
Interface: | VGA (D-Sub) |
---|---|
Operating system: | - |
Included software: | - |
Supported image formats (Windows): | - |
Supported video formats (Windows): | - |
Supported image formats (MacOS): | - |
Supported video formats (MacOS): | - |
Imaging standards: | - |
Housing
Housing material: | Composite/ plastic housing |
---|---|
Magnification lock: | Yes |
Dimensions: | 10.5cm (L) x 3.2cm (D) |
Weight: | 105g |
Cable length: | 0.6m |
Features
Special feature: | No |
---|---|
Measurement: | No |
Calibration: | No |
Microtouch sensor: | Yes |
ESD safe: | No |
Information
Package contents: | Microscope, Carry pouch, Power adapter, Front cover box, User manual | ||||||||||||||||||||||||||||||||||||||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Warranty information: | 2 years European warranty | ||||||||||||||||||||||||||||||||||||||||||||||||||
Regulatory approval: | CE, FCC, ROHS | ||||||||||||||||||||||||||||||||||||||||||||||||||
Price range: | €350,00 - €550,00 | ||||||||||||||||||||||||||||||||||||||||||||||||||
Working distance/ field of view/ depth of field: |
|
Execution | TEC |
---|---|
Manufacturer Nr. | AM5216ZT |
Manufacturer | Dino-Lite |
Country of Manufacture | Taiwan, Province of China |
EAN | 4712805476657 |
ESD equipment | USB Mikroskop |
Lead time | 1 week |
Weight | 0.105000 |
HS-Code | 90119090 |
