Bosch Rexroth 3842998708. Static friction chain VFplus 120, AZ=2-84

Static friction chain VFplus 120, AZ=2-84

• The static friction chain enables the transport of products on ascending or descending sections. The number of chain links with static friction lining can be specified by the user depending on the product size, weight and the inclination.
• Transport on uphill or downhill gradients up to about 30° possible. Maximum gradient depends on the product surface, section length, and speed (test required)
• Accumulation operation not permitted
• From size 160: Chain plate easy to replace
• Only suitable for dry operation
• AZ ≥ 2: Static friction chain supplemented with flat conveyor chain links (AZ = spacing distance)
  AZ = 1: All chain links with static friction coating
• The grip is maintained through regular cleaning
• The chain coating is not suitable for transporting sharp-edged objects
• Extremely quiet chain running thanks to the patented chain design
• Large-area static friction lining for secure product transport
