Lead time
1 week
€379.00
Excl. 19% VAT , excl. Shipping Cost
Article
AM4113FVT2
Manufacturer Nr.
AM4113FVT2
The AM4113FVT2 has special lighting with LED's emitting UV light around the 375 nm spectrum. » Also available with ~400 nm LEDs (model AM4113FVT).
Frequently Bought Together
- This Item: €379.00Excl. 19% VAT , excl. Shipping Cost
- Dino-Lite AM7515MT4A €1,079.00Excl. 19% VAT , excl. Shipping Cost
- Dino-Lite DermaScope Polarizer HR €1,168.83Excl. 19% VAT , excl. Shipping Cost
Total price
Additional Info
Dino-Lite range: | Dino-Lite Special lighting |
---|
Lighting
Light/ LED type: | ~375 nm UV |
---|---|
Number of LEDs: | 4 |
LED on/off switchable: | Yes |
Infrared filter: | IR cut-filter >650 nm |
Diffuser available: | No |
Emission filter: | Yes, Emission barrier filter 375 nm |
Polarizer: | No |
Optics
Magnification: | 10-70x, 200x |
---|---|
Macro zoom: | No |
Working distance: | Standard |
Lens type: | Glass with anti-reflection coating |
Sensor
Sensor type: | CMOS |
---|---|
Resolution: | 1.3 Megapixel (1280x1024) |
Maximum frame rate: | 30 fps |
Compatibility
Interface: | USB 2.0 |
---|---|
Operating system: | Windows XP, Vista, 7, 8 & 10, MacOS 10.9 and up |
Included software: | DinoCapture 2.0 (Windows), DinoXcope (Mac OS) |
Supported image formats (Windows): | BMP, GIF, PNG, JPG, TIF, RAS, PNM, TGA, PCX, MNG, WBMP, JP2, JPC, PGX |
Supported video formats (Windows): | WMV, FLV, SWF |
Supported image formats (MacOS): | JPEG, PNG |
Supported video formats (MacOS): | MOV |
Imaging standards: | DirectShow, UVC |
Housing
Housing material: | Composite/ plastic housing |
---|---|
Magnification lock: | Yes |
Dimensions: | 10.5cm (L) x 3.2cm (D) |
Weight: | 105g |
Cable length: | 1.8m |
Features
Special feature: | No |
---|---|
Measurement: | Yes |
Calibration: | Yes |
Microtouch sensor: | Yes |
ESD safe: | No |
Information
Package contents: | Microscope, Carry pouch, Software CD, Calibration target, User manual | ||||||||||||||||||||||||||||||||||||||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Warranty information: | 2 years European warranty | ||||||||||||||||||||||||||||||||||||||||||||||||||
Regulatory approval: | CE, FCC, ROHS | ||||||||||||||||||||||||||||||||||||||||||||||||||
Price range: | €200,00 - €350,00 | ||||||||||||||||||||||||||||||||||||||||||||||||||
Working distance/ field of view/ depth of field: |
| ||||||||||||||||||||||||||||||||||||||||||||||||||
Special Light: |
Execution | TEC |
---|---|
Manufacturer Nr. | AM4113FVT2 |
Manufacturer | Dino-Lite |
Country of Manufacture | Taiwan, Province of China |
EAN | 4712805475230 |
ESD equipment | USB Mikroskop |
Lead time | 1 week |
Weight | 0.009900 |
HS-Code | 90119090 |
