Lead time
1 week
€829.00
Excl. 19% VAT , excl. Shipping Cost
Article
AM4115T-GRFBY
Manufacturer Nr.
AM4115T-GRFBY
The Dino-Lite AM4115T-GRFBY digital microscope is optimized for research and viewing fluorescent objects by using 480nm and 575nm excitation LEDs. It has a 510nm and 610nm emission filter that is designed to observe a wide range fluorophores with applications in developmental biology, pathology, and anatomy. The AM4115T-GRFBY has the capability of switching the light source from the 480nm excitation LEDs to the 575nm LED, which is convenient for dual color stained fluorescence. All of these factors make the AM4115T-GRFBY the smallest fluorescence microscope in the world, capable of many applications and visualizing a vast range of fluorescence. » Special models available on request.
Frequently Bought Together
- This Item: €829.00Excl. 19% VAT , excl. Shipping Cost
- Dino-Lite AM4023CT €249.00Excl. 19% VAT , excl. Shipping Cost
- Dino-Lite CA1070 €32.50Excl. 19% VAT , excl. Shipping Cost
Total price
Additional Info
Dino-Lite range: | Dino-Lite Special lighting |
---|
Lighting
Light/ LED type: | 480nm excitation + 575nm excitation |
---|---|
Number of LEDs: | 4 FL + 4 FL |
LED on/off switchable: | Yes |
Infrared filter: | No |
Diffuser available: | No |
Emission filter: | 510nm & 610nm |
Fluorophores: | GFP/FITC & TxRed/mCherry |
Polarizer: | No |
Optics
Magnification: | 20-220x |
---|---|
Macro zoom: | No |
Working distance: | Standard |
Lens type: | Glass with anti-reflection coating |
Sensor
Sensor type: | CMOS |
---|---|
Resolution: | 1.3 Megapixel (1280x1024) |
Maximum frame rate: | 30 fps |
Compatibility
Interface: | USB 2.0 |
---|---|
Operating system: | Windows XP, Vista, 7, 8 & 10, MacOS 10.9 and up |
Included software: | DinoCapture 2.0 (Windows), DinoXcope (Mac OS) |
Supported image formats (Windows): | BMP, GIF, PNG, JPG, TIF, RAS, PNM, TGA, PCX, MNG, WBMP, JP2, JPC, PGX |
Supported video formats (Windows): | WMV, FLV, SWF |
Supported image formats (MacOS): | JPEG, PNG |
Supported video formats (MacOS): | MOV |
Imaging standards: | DirectShow, UVC |
Housing
Housing material: | Composite/ plastic housing |
---|---|
Magnification lock: | Yes |
Dimensions: | 10.5cm (L) x 3.2cm (D) |
Weight: | 105g |
Cable length: | 1.8m |
Features
Special feature: | No |
---|---|
Measurement: | Yes |
Calibration: | Yes |
Microtouch sensor: | Yes |
ESD safe: | No |
Information
Package contents: | Microscope, Carry pouch, Software CD, Calibration target, User manual | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Warranty information: | 2 years European warranty | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Regulatory approval: | CE, FCC, ROHS | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Price range: | €550,00 - €750,00 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Working distance/ field of view/ depth of field: |
| ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Special Light: |
Execution | TEC |
---|---|
Manufacturer Nr. | AM4115T-GRFBY |
Manufacturer | Dino-Lite |
Country of Manufacture | Taiwan, Province of China |
EAN | 4712805475780 |
ESD equipment | USB Mikroskop |
Lead time | 1 week |
Weight | 0.009900 |
HS-Code | 90119090 |
