Festo OGGB-100-G18-2-Q (574566) Bernoulli Gripper
€337.58
Excl. 19% VAT , excl. Shipping Cost
Article
FES-574566
Manufacturer Nr.
OGGB-100-G18-2-Q
Bernoulli Gripper
Frequently Bought Together
- This Item: €337.58Excl. 19% VAT , excl. Shipping Cost
- Festo ESV-30-EN (191027) Vacuum Suction Cup €8.56Excl. 19% VAT , excl. Shipping Cost
- Festo ESV-40-SU (190990) Vacuum Suction Cup €12.60Excl. 19% VAT , excl. Shipping Cost
Total price
| installation position | arbitrary |
| Connection position | Top/side |
| Gripper diameter [mm] | 100 |
| Operating pressure [bar] | 0 to 6 |
| Nominal operating pressure [bar] | 1 |
| Air consumption a nominal operating pressure [l/min] | 110 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Information about operating and control medium | Oiled operation not possible |
| Corrosion resistant class KBK | 2 - moderate corrosion stress |
| Medium temperature [°C] | 0 to 60 |
| ambient temperature [°C] | 0 to 60 |
| Noise level for nominal operating pressure [dB(A)] | 65 |
| Noise performance level for nominal operating pressure [dB(A)] | 78 |
| Holding force for nominal operating pressure [N] | 6 |
| Shear force for nominal operating pressure [N] | 12 |
| Fastening type | with female thread |
| Pneumatic connection | G1/8 |
| Alternative connections | G1/8 |
| Material information | RoHs compliant |
| Housing material | Aluminium wrought alloy anodized |
| Spacer element material | NBR POM |
| Product weight [g] | 210 |
| Manufacturer Nr. | OGGB-100-G18-2-Q |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568223618 |
| Weight | 0.350000 |
| HS-Code | 84798997 |
