cab 8936510. PCB Separator Maestro 6/603, cut-off length 600 mm

Cutting of pre-scored PCBs up to 1,500 mm length with minimum stress on components
The MAESTRO 6 is the consequent further development of the proven cab depanelling machines.
Even very long panels are separated quickly, economically and stress-free.
The carriage drive is located directly behind the linear knife.
This simplifies the separation and removal of the PCBs considerably.

• Cutting length up to 600 mm
• Easy and quick change of FR4/CEM-3 knives to aluminium knives and back again
• Distance of the roller knives to the linear knife individually adjustable
• Rolling knife diameter 60 mm
• Component height: assembly side up to 10 mm, solder side up to 22 mm
• width x depth x height: 1150 x 350 x 450 mm
• Weight: 50 kg
• Separation principle: placement side roller blade, solder side linear blade
• Separation process: path-optimized
• Cutting speed up to 500 mm/s, up to 250 mm/s for aluminium
• Deposit table depth: 160 mm
• Voltage 100-240 VAC, 50/60 Hz
• Emission sound pressure level LpA < 70 dB (A)
• Approvals CE, FCC Class A
