Solder Baths (pots)
Ersa Soldering Technology
Ersa solder baths in the form of i-Solder-Pot mini crucibles enable tinning and tip cleaning directly on the ERSA i-Tool handpiece. The compact internal dimensions (22x10x10 mm to 44x10x10 mm) fit the tip connection of the i-Tool and hold a small amount of solder to remove residues and re-wet the tip. Versions with 20x6 mm and only 10 mm depth (0102XP2006) serve very fine-tipped tools with a narrow working radius.
i-Tool compatible - mini crucibles mount directly to the ERSA i-Tool handpiece connection
Internal length 22-44 mm - graded crucible sizes for different tip geometries
Tip care at the handpiece - tip wetting and cleaning without setting down the handpiece
19 articles - mini crucibles and replacement baths for i-Tool in stock
| Part number | Internal dim. | Depth | Target tip |
|---|---|---|---|
| 0102XP2210 | 22x10 mm | 10 mm | Narrow i-Tool tips |
| 0102XP3210 | 32x10 mm | 10 mm | Standard i-Tool tips |
| 0102XP3810 | 38x10 mm | 10 mm | Wider i-Tool tips |
| 0102XP2006 | 20x6 mm | 10 mm | Fine tips with narrow radius |
| 0102XP4410 | 44x10 mm | 10 mm | Wide chisel tips i-Tool |
Typical applications: Regular tip care and re-wetting during extended SMD and THT soldering sessions, cleaning of tips after use with lead-free SAC solders, maintenance in electronics production using ERSA i-Tool stations, and quality assurance through regular tinning to extend tip service life.
