What are vacuum pipettes and what industrial applications do they serve?
Vacuum pipettes are precision handling tools that use controlled suction to safely lift, position, and manipulate delicate electronic components, semiconductor devices, and small mechanical parts without physical contact damage. These instruments are essential in electronics manufacturing, laboratory environments, and precision assembly operations where static-sensitive components require ESD-safe handling. Professional vacuum pipettes like the WELLER WLSK200 and PEN-VAC models enable technicians to securely grip components ranging from 3mm to 19.05mm diameter while maintaining contamination-free workflows in cleanroom and production environments.
What technical specifications should I consider when selecting vacuum pipettes for component handling?
Critical selection criteria for vacuum pipettes include tip diameter compatibility ranging from 3mm to 19.05mm as demonstrated by available ESD suction nozzles, vacuum generation method whether manual or powered, and ESD surface resistance compliance for electronics applications. The HANDI-VAC series offers manual operation suitable for intermittent use, while powered units like the WELLER WLSK200 provide consistent vacuum levels for high-volume production. Tip geometry varies between straight and angled configurations such as the T1-S series straight nozzles and T1-B angled variants, with material compatibility determining whether components can be safely lifted without surface marking or contamination transfer.
Which international standards and certifications apply to industrial vacuum pipettes?
Professional vacuum pipettes must comply with IEC 61340-5-1 standards for electrostatic discharge control in electronics handling, ensuring surface resistance values between 10⁶ and 10⁹ ohms for ESD-safe operation. Components used in cleanroom environments require ISO 14644 classification compatibility, while tools handling semiconductor devices must meet SEMI S2 and S8 standards for contamination control. Medical and laboratory applications demand ISO 13485 quality management compliance, and vacuum generation systems must conform to relevant pressure vessel directives when operating above atmospheric pressure differentials exceeding 0.5 bar absolute.
What are the main differences between manual and powered vacuum pipette variants?
Manual vacuum pipettes like the HANDI-VAC HV-4-ESD and HV-6-ESD models generate suction through thumb-operated pumps, providing precise control and unlimited operation time without power requirements, making them ideal for laboratory and low-volume assembly applications. Powered units such as the WELLER WLSK200 deliver consistent vacuum levels through integrated pumps, enabling continuous operation and reducing operator fatigue during high-volume production runs. The PEN-VAC V8901-LMS-ESD represents a hybrid approach with battery operation, combining portability with reliable suction performance. Tip interchange systems vary between manufacturers, with dedicated ESD nozzle series offering diameters from 3mm straight variants to 12.7mm angled configurations for specialized component geometries.
What installation and system compatibility requirements exist for vacuum pipettes?
Most vacuum pipettes operate as standalone handheld units requiring no installation beyond tip selection and ESD grounding verification, with models like the HANDI-VAC series ready for immediate use after unpacking. Powered units may require battery charging or AC adapter connection, while integrated systems demand compressed air supply at 4-6 bar working pressure for pneumatic vacuum generation. ESD compliance requires verification of continuous ground path from operator through wrist strap to tool body, with surface resistance measurement confirming values within IEC 61340-5-1 specifications. Tip compatibility follows manufacturer-specific threading or push-fit connections, with universal tips available for cross-platform applications across different vacuum pipette brands and models.
What safety ratings and operating parameters apply to vacuum pipettes in industrial environments?
Industrial vacuum pipettes typically operate within temperature ranges of -10°C to +60°C for standard models, with specialized variants extending to +80°C for elevated temperature applications in electronics manufacturing. Maximum vacuum levels reach -0.8 bar absolute for manual units and -0.9 bar for powered systems, providing sufficient lifting force for components up to 50 grams depending on surface area and material properties. ESD-safe models maintain surface resistance between 10⁶ and 10⁹ ohms per IEC 61340 requirements, while IP40 ingress protection represents typical ratings for handheld units in workshop environments. Operating humidity ranges from 20% to 80% relative humidity without condensation, ensuring reliable performance across varying cleanroom and laboratory conditions.
What maintenance schedules and inspection requirements apply to vacuum pipettes?
Vacuum pipettes require daily visual inspection of tip condition and vacuum line integrity, with weekly cleaning using isopropyl alcohol to remove contamination from ESD surfaces and component contact areas. Monthly calibration verification involves vacuum level measurement using precision gauges to ensure -0.7 to -0.9 bar performance within manufacturer specifications, while quarterly ESD resistance testing confirms surface values remain within IEC 61340-5-1 compliance ranges of 10⁶ to 10⁹ ohms. Annual comprehensive service includes pump mechanism inspection, seal replacement, and complete electrical continuity verification for powered units. Service life typically extends 3-5 years for manual units and 2-3 years for powered models under normal industrial usage, with tip replacement intervals varying from monthly to quarterly depending on component abrasiveness and handling frequency.

Vacuum pipettes

Handwerkzeuge

View as Grid List

19 Items

Set Ascending Direction
  1. WELLER WLSK200. WLSK 200 Vacuum-Pen including Tip 3,2 mm x 9,5 mm
    Add to Wish List Add to Compare
    WELLER WLSK200. WLSK 200 Vacuum-Pen including Tip 3,2 mm x 9,5 mm
    €116.96
    Excl. 19% VAT , excl. Shipping Cost
  2. E V8901-LMS-ESD. PEN-VAC vacuum pipette
    Add to Wish List Add to Compare
    E V8901-LMS-ESD. PEN-VAC vacuum pipette
    €98.00
    Excl. 19% VAT , excl. Shipping Cost
  3. E HV-6-ESD. Vacuum pipette HANDI-VAC
    Add to Wish List Add to Compare
    E HV-6-ESD. Vacuum pipette HANDI-VAC
    €48.00
    Excl. 19% VAT , excl. Shipping Cost
  4. E HV-4-ESD. HANDI-VAC vacuum pipette
    Add to Wish List Add to Compare
    E HV-4-ESD. HANDI-VAC vacuum pipette
    €35.17
    Excl. 19% VAT , excl. Shipping Cost
  5. E V 9075-ESD. ESD suction cup 19.05 mm
    Add to Wish List Add to Compare
    E V 9075-ESD. ESD suction cup 19.05 mm
    €10.51
    Excl. 19% VAT , excl. Shipping Cost
  6. T1-S12-ESD. ESD vacuum extraction nozzle 12.7 mm, straight
    Add to Wish List Add to Compare
    T1-S12-ESD. ESD vacuum extraction nozzle 12.7 mm, straight
    €9.50
    Excl. 19% VAT , excl. Shipping Cost
  7. E T1-B3-ESD. ESD vacuum suction nozzle 3 mm
    Add to Wish List Add to Compare
    E T1-B3-ESD. ESD vacuum suction nozzle 3 mm
    €9.50
    Excl. 19% VAT , excl. Shipping Cost
  8. E T1-B9-ESD. ESD vacuum suction nozzle 9 mm
    Add to Wish List Add to Compare
    E T1-B9-ESD. ESD vacuum suction nozzle 9 mm
    €9.50
    Excl. 19% VAT , excl. Shipping Cost
  9. E T1-S3-ESD. ESD vacuum suction nozzle 3 mm
    Add to Wish List Add to Compare
    E T1-S3-ESD. ESD vacuum suction nozzle 3 mm
    €9.50
    Excl. 19% VAT , excl. Shipping Cost
  10. E T1-S6-ESD. ESD vacuum suction nozzle 6 mm
    Add to Wish List Add to Compare
    E T1-S6-ESD. ESD vacuum suction nozzle 6 mm
    €9.50
    Excl. 19% VAT , excl. Shipping Cost
  11. E T1-S9-ESD. ESD vacuum suction nozzle 9 mm
    Add to Wish List Add to Compare
    E T1-S9-ESD. ESD vacuum suction nozzle 9 mm
    €9.50
    Excl. 19% VAT , excl. Shipping Cost
  12. E V 9062-ESD. ESD suction cup 15.87 mm
    Add to Wish List Add to Compare
    E V 9062-ESD. ESD suction cup 15.87 mm
    €8.50
    Excl. 19% VAT , excl. Shipping Cost
  13. T1-B6-ESD. ESD vacuum suction nozzle 6 mm
    Add to Wish List Add to Compare
    T1-B6-ESD. ESD vacuum suction nozzle 6 mm
    €7.51
    Excl. 19% VAT , excl. Shipping Cost
  14. E T1-B12-ESD. ESD vacuum extraction nozzle 12.7 mm, angled
    Add to Wish List Add to Compare
    E T1-B12-ESD. ESD vacuum extraction nozzle 12.7 mm, angled
    €7.50
    Excl. 19% VAT , excl. Shipping Cost
  15. E V 9025-ESD. ESD suction cup 6.35 mm
    Add to Wish List Add to Compare
    E V 9025-ESD. ESD suction cup 6.35 mm
    €6.50
    Excl. 19% VAT , excl. Shipping Cost
  16. E V 9013-ESD. ESD suction cup 3.56 mm
    Add to Wish List Add to Compare
    E V 9013-ESD. ESD suction cup 3.56 mm
    €6.50
    Excl. 19% VAT , excl. Shipping Cost
  17. V 9050-ESD. ESD suction cup 12.70 mm
    Add to Wish List Add to Compare
    V 9050-ESD. ESD suction cup 12.70 mm
    €6.50
    Excl. 19% VAT , excl. Shipping Cost
  18. E V 9038-ESD. ESD suction cup 9.53 mm
    Add to Wish List Add to Compare
    E V 9038-ESD. ESD suction cup 9.53 mm
    €6.20
    Excl. 19% VAT , excl. Shipping Cost
  19. S3955-B-ESD. ESD vacuum suction nozzle
    Add to Wish List Add to Compare
    S3955-B-ESD. ESD vacuum suction nozzle
    €5.84
    Excl. 19% VAT , excl. Shipping Cost
per page

Vacuum pick-up pens and vacuum pipettes deliver controlled, contact-minimised component handling for surface-mount devices, bare dies, and fragile substrates as small as 0402 (1.0 x 0.5 mm). Working vacuum levels typically range from -20 to -80 kPa, with interchangeable ESD-safe silicone tips covering suction cup diameters from 0.5 mm to 12 mm. High-quality units meet IEC 61340-5-1 surface resistance requirements (10⁵-10⁹ Ω) throughout the tool body and tip, preventing electrostatic discharge to sensitive CMOS and BGA components rated below 100 V HBM.

This catalogue lists 19 vacuum pipette references - from manual squeeze-bulb pens to pump-assisted precision picks - suited to SMT rework, IC placement, laboratory handling, and clean-room assembly. All stocked models comply with EN 61340-5-1/5-2 EPA tool requirements and are available for immediate dispatch.

Key technical advantages - Vacuum Pipettes at a glance
⚡ 10⁵-10⁹ Ω body resistance - ESD-safe tool body per IEC 61340-5-1
⚙ 0.5-12 mm tip range - interchangeable silicone cups for 0402 to large BGAs
🛠 -20 to -80 kPa vacuum - adjustable suction for delicate and heavy components
🔍 Sub-gram placement force - prevents mechanical stress on fragile dies and lenses
🛡 EN 61340-5-2 compliant - certified for use inside EPA environments
✓ 19 references in stock - manual and pump-assisted models, ready for same-day dispatch

Typical application areas: SMT rework and component placement (IPC-7711/7721, IEC 61340-5-1), bare-die and flip-chip handling (JEDEC JESD625), optical and MEMS assembly (ISO 10110), laboratory sample manipulation (ISO 13485 clean-room environments), automotive electronics production (IATF 16949, VDA 6.3), and semiconductor back-end packaging (SEMI S1/S2).

✓
EPA-Compliant Tools All vacuum pipettes meet IEC 61340-5-1 and EN 61340-5-2 for certified ESD-safe workplaces
📦
19 Models in Stock Manual squeeze-bulb pens, pump-assisted picks, and complete tip sets - ready for immediate dispatch
🛡
Precision Handling Tip diameters from 0.5 mm - safe pick-up of 0402 passives, bare dies, and optical components
