Workplace lighting
Workplace luminaires
Workplace luminaires put the light where the work happens: above the bench, the assembly station and the inspection desk. The range runs from the compact clamp lamp to the long bench luminaire, among others from Starlight, Glamox and LED2WORK. Luminous flux runs from 105 lm to 11394 lm and the light colour from 3000 K warm white to 6500 K, with Ra 90 and Ra 98 available for colour and paint checks. Mounting is on an articulated arm, a table clamp, a magnetic holder or a base, and power comes from 24 V, 48 V or the mains.
- Selection criteria
- Frequently asked questions
- Machine luminaires
- System luminaires
- Articulated and flexible arm luminaires
Straight to the right workplace luminaire
The most common requirements as ready-made filters inside this category.
Articulated armPositioned freely above bench and inspection desk.swivels and tilts
Table clampClamps onto the edge of the table top.no drilling
Ra 90True colour rendering for checking and inspection.
3000 KWarm light for assembly and permanent stations.warm white
Tunable whiteLight colour chosen to suit the task.adjustable light colour
DimmableBrightness matched to the task and to daylight.
IP67Sealed against dust, chips and splash water.temporary immersion
24 VRuns off an existing system power supply.low voltage
- 153 items
- 9 manufacturers
- Net prices plus VAT
Buying guide
How to choose Workplace luminaires
What matters when choosing: properties, comparison and typical applications.
Selection criteria
| Criterion | In this category | Note |
|---|---|---|
| Mounting | Articulated arm, table clamp, magnetic holder, base | Articulated arm for changing working heights, clamp for fixed stations. |
| Luminous flux | 105 lm to 11394 lm | Fine assembly and visual inspection need far more light than a storage shelf. |
| Light colour | 3000 K, 4000 K, 5000 K, 5500 K, 5700 K, 6000 K, 6500 K, tunable white | Warm white for continuous work, neutral and cool white for inspection. |
| Colour rendering | Ra 85, Ra 90, Ra 98 | Ra 90 and above for colour and paint checks. |
| Beam angle | 6° to 118° | Narrow angles create accents, wide angles cover the whole surface. |
| Protection rating | IP20, IP40, IP50, IP52, IP65, IP67 | IP65 and IP67 for dust, chips and splash water. |
| Power | 3 W to 500 W | Wattage alone says little, compare the luminous flux as well. |
| Supply voltage | 100-240 V, 24 V, 48 V, 110-240 V, 100-305 V, 230 V, 5 V | 24 V and 48 V suit existing workstation systems. |
| ESD | TEC, ESD (antistatic) | Marking for workplaces inside an EPA. |
Frequently asked questions
- Which mounting suits a workbench?
- The articulated arm is the most flexible solution, it swings across the work surface and adjusts in height. The table clamp requires a free table edge, the magnetic holder a ferromagnetic surface, and the base needs no fixing at all.
- Which light colour suits assembly and inspection?
- Warm white at 3000 K is comfortable at permanent stations. For visual and colour inspection, 5000 K to 6500 K works better because contrast stands out more clearly. For changing tasks, luminaires with tunable white let you set the light colour yourself.
- When do I need high colour rendering?
- For colour checks, paint inspection and work on colour-coded wiring. Luminaires with Ra 90 and Ra 98 cover that, while Ra 85 is enough for plain assembly steps.
- Are there luminaires for ESD workplaces?
- Yes. In the ESD attribute, luminaires are marked TEC or ESD (antistatic), and both suit workplaces inside an EPA.
- Which supply voltage is common?
- Mains operation at 100-240 V or 230 V is the rule. Low voltage at 24 V or 48 V makes sense when the luminaire is fed from an existing workstation system.
