Electromechanical cylinders
Bosch Rexroth electromechanical cylinders (EMC series) convert the rotary motion of a servo motor into precise linear movement. The range primarily covers compensation couplings for cylinder series EMC32, EMC40, EMC50/63, and EMC100XC, which provide a misalignment-tolerant connection between the motor shaft and the cylinder drive. Couplings with M36x2 thread (EMC100XC) and their counterparts for EMC32, EMC40, and EMC50/63 allow installation even with slight angular deviations without affecting the cylinder's positioning accuracy.
- 154 items
- 1 manufacturer
- Net prices plus VAT
Buying guide
How to choose Electromechanical cylinders
What matters when choosing: properties, comparison and typical applications.
Technical features
Coupling overview by size
| Article no. | Cylinder size | Connection dimension |
|---|---|---|
| R349939700 | EMC32 | Compensation coupling |
| R349939800 | EMC40 | Compensation coupling |
| R349939900 | EMC50/63 | Compensation coupling |
| R349950900 | EMC100XC | M36x2 |
| R349951100 | EMC100XC | M36x2 (variant) |
Typical applications
Typical applications: Electric replacement for pneumatic cylinders in handling and assembly stations, press and joining axes in automotive electronics, dispensing and positioning tasks with programmable stroke and force, test bench axes with defined force and displacement profiles, and retrofitting existing pneumatic linear axes with energy-efficient electric drives.
