Superform forming tools

Component processing

Iteco Superform machines cut and form the leads of axial and radial leaded components - whether taped or loose - and prepare them for automatic or manual THT placement. Selectable pitches (e.g. 5.08 and 7.62 mm) and various forming versions (V, AF, VP) cover nearly all common component styles.

esd.equipment supplies the Superform range with accessories: component-holder sets, micro-adjustment for the preform height, guide units and waste-tape ejectors - for consistent, IPC-compliant component forming and repeatable placement quality.

Cutting and forming in one operation - axial and radial components, taped or loose

Selectable pitches - e.g. 5.08 mm and 7.62 mm lead spacing

Micro-adjustment of preform height - fine adaptation to component geometry

Repeatable forming - consistent quality to IPC-A-610

Waste-tape ejector - clean separation of tape and component

Retrofittable holder sets - flexible for different component styles

Superform - overview by component type

Version	Component type	Feed
Superform/V	axial components	taped
Superform/AF	axial components	taped, reinforced version
Superform/VP	radial components	taped
Accessories	loose components	component-holder sets

Typical applications: THT assembly in series and contract manufacturing, power and industrial electronics, preparation of resistors, diodes and capacitors for automatic placement, and small series with frequent component changes.

Genuine Iteco machinesSuperform range and accessories

Modularly expandableholders and adjustments retrofittable

Process advicesizing by component type and pitch
