Automatic cartridge stand for R245 soldering cartridges, pneumatic, tilts up to 35 degrees - JBC CS2R245-A

The CS2R245-A is the automatic cartridge stand for JBC R245 soldering cartridges, designed for automated soldering cells with Cartesian and SCARA robots. The mechanism uses compressed air to lock or release cartridges fully automatically, so the robot can change tip geometries without operator intervention.

Benefits

• Pneumatic mechanism locks and releases the R245 cartridges automatically during the process
• Position tilts up to 35 degrees to either side to match the working position
• Two gripper actuators work like a cassette magazine: the robot uses different tip geometries or swaps a worn cassette automatically
• Poka-yoke holder places the cartridge in a defined position and secures repeatability of the tip position
• Cleaning unit tilts 70 degrees for easy tip cleaning with Cartesian and SCARA robots
• Compact format of 153 x 82 x 97 mm at only 0.69 kg

Technical data

Applications

Suited to automated soldering processes and standard soldering work in robot-based production cells where cartridges must be changed and cleaned without manual intervention.

Compatibility and scope of delivery

Combines with the TRA245 automatic iron and the UCR245 control box. Designed for R245 soldering cartridges. Scope of delivery: 1 cartridge stand CS2R245-A.

Made by JBC, Spain. Compliant with CE and RoHS.
