Polyimide adhesive tape, high temperature resistant, 20 mm x 33 m - Warmbier WL33781

Warmbier polyimide adhesive tape serves as masking tape to protect contact areas and holes on PCBs during the wave soldering process. It withstands temperatures up to 230 C and removes with little residue after soldering.

Benefits

• Temperature resistant up to 230 C for wave and reflow processes
• Very good chemical resistance
• Dissipative with minimised charging behaviour

Technical specifications

• Width: 20 mm
• Length: 33 m
• Material: polyimide
• Typical resistance to ground: 10⁶ to 10⁸ ohm
• Underside: insulating
• Core diameter: 76 mm
• Selling unit: 1 roll

Applications

Masking of gold contacts, connectors and holes before soldering in electronics manufacturing.

Standards

Suitable for use in the ESD protected area according to IEC 61340-5-1.
