The most compact hot-air station on the market for high-precision SMD rework on ultra-small components from 01005 under the microscope. 70 W, adjustable airflow 0.15 to 2.5 SLPM and an integrated pick-and-place vacuum function with pedal. ESD-safe to ANSI/ESD S20.20-2021.
Precision hot-air station 70 W, 150-450 °C, ESD, for 01005 SMD - JBC JNA-2B
JBC
Original product
Net price (excl. VAT)
€2,045.65
Item
WL81281
Manufacturer no.
JNA-2B
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.JNA-2B
Country of originSpain
Customs tariff number85152900000
ConditionNew
Article
WL81281
Frequently Bought Together
-
This Item:
€2,045.65
-
Compact Line precision soldering station with T210-A iron - JBC CD-2SQF
€506.13
-
Hot air station 700 W, 150 to 450 °C, with hot air iron and stand - JBC JTSE-1B
€2,225.08
Total price
The JBC JNA-2B is a precision hot-air station for SMD rework on ultra-small components from package 01005 under the microscope. Its compact footprint (170 x 180 x 110 mm) allows work in tight spaces without thermally stressing adjacent components.
Benefits
- Fine airflow control from 0.15 to 2.5 SLPM for controlled heating of sensitive components.
- Temperature range 150 to 450 °C for a wide span of lead-free and leaded processes.
- Integrated vacuum pump with pick-and-place function (53 % vacuum / 397 mmHg) for safe pickup and placement of small components via pedal.
- Two operating modes (manual and programmed) for repeatable repair routines.
- ESD-safe design to ANSI/ESD S20.20-2021 with equipotential bonding to the EPA.
- USB-A for firmware, graphics and profiles plus USB-B for PC communication; RJ12 to connect a remote control or the FAE fume extractor.
Technical data
| Model | JNA-2B |
| Article number | JNA-2B |
| Station type | Hot-air station |
| Rated power | 70 W |
| Temperature range | 150 to 450 °C |
| Airflow | 0.15 to 2.5 SLPM |
| Vacuum | 53 % / 397 mmHg / 15.6 inHg |
| Interfaces | USB-A, USB-B, RJ12, pedal connection |
| Dimensions | 180 x 170 x 110 mm |
| Net weight | 4.06 kg |
| ESD-safe | yes (ANSI/ESD S20.20-2021) |
Applications
SMD rework and repair of the smallest components from 01005, work under the microscope, research and development, and repair benches with limited space.
Compatibility and scope of delivery
Suitable for the J125410 and J325410 handpieces. Supplied with the control unit, the NH-A precision hot-air iron, the NAS stand, two hot-air nozzles (Ø 1.0 mm and 3.0 mm), the T260-A pick-and-place vacuum tool with bent needles and suction cups, and the P-405 foot switch.
CE, RoHS, ESD-safe to ANSI/ESD S20.20-2021. Country of origin Spain.
| Norm | ANSI/ESD S20.20 |
|---|---|
| ESD version | ESD (antistatic) |
| Manufacturer Nr. | JNA-2B |
| Manufacturer | JBC |
| Country of Manufacture | Spain |
| Weight | 4.060000 |
| HS-Code | 85152900000 |
| GPSR manufacturer information | JBC Soldering SL Ramón y Cajal 3 ES-08750 Molins De Rei www.jbctools.com |
| Article authenticity | Original product |
| Condition of article | New |
| Power | 70 W |
| Temperature range | 150-450 °C |
| Temperature (max.) | up to 450 °C |
