ESD Foam Sheet XLPE ELXAC50 Conductive, 353 x 253 x 6 mm, Black - A1-ESD EP0705146

Holding components in place inside a transport container without letting the packaging build up a charge is what this insert is for. The XLPE foam ELXAC50 sheet measures 353 x 253 mm at 6 mm thickness and is set to a conductive range of 10E3 to 10E6 ohm, so charges drain away in a controlled manner instead of collecting in the material. The firm grade keeps its shape while doing so.

Benefits

• Conductive at 10E3 to 10E6 ohm, charges are drained instead of stored in the material.
• Firm grade, the sheet holds its shape even with assemblies resting on it.
• 353 x 253 mm cut size for use as a bottom, interlayer or top pad in ESD containers and cartons.
• 6 mm of material thickness, matched to the height the container allows.
• Black throughout, so it is told apart from ordinary packaging foam on the shelf.

Technical data

Application

Inside the ESD protected area the sheet serves as an insert in cartons, stacking containers and workpiece carriers. Typical contents are populated boards, connectors and small parts that must neither shift between two operations nor touch a charged surface. The foam can be trimmed with a knife to the inner dimensions of the container.

The series covers further thicknesses (10 mm and 15 mm). This article is the 6 mm version.
