Electrical connection technology

Festo pneumatics

Festo electrical connection technology covers pre-assembled cables, connectors, and accessories for connecting valves, sensors, and actuators in pneumatically and electrically controlled systems. The programme is divided into connection and socket cables of the KMC/KMEB/KMF/KMV series, socket outlets and indicator plugs of the MSSD and MCL/MFL families, and cable glands, cable ties, and sealing accessories from the NETC/NEAM range.

Categories
Lines LinesConnection cables KMC, socket cables KMEB/KMF/KMV, 24 VDC and 230 VAC Festo Connectors ConnectorSocket outlets MSSD, indicator plugs MCL/MFL, illuminated seals Accessories electrical connection technology Festo Accessories for electrical connection technologyCable glands NETC, cable ties NEAM, sealing components

⚙ Cables 24 VDC and 230 VAC - series KMC/KMEB/KMF/KMV, lengths 2.5 m, 5 m, and 10 m
✓ LED indicator cables - KMEB-1-24-LED, KMF-1-24DC-LED, KMV-1-24DC-LED with integrated switching status indication
⛤ Socket outlets MSSD-C/E/F/V - standard valve sockets with M16, M14, and special variants
📦 Indicator plugs MCL/MFL/MCLZ - LED indication 24 VDC/230 VAC, time-delay intermediate plug MFZ
⚡ Cable glands NETC M12/M20 - standard and Ex versions for valve boxes and control cabinets
✨ System-matched - all components designed for Festo valve sockets and cable cross-sections

SeriesVoltageLengthFeature
KMC-124 VDC, 230 VAC2.5 / 5 / 10 mConnection cable
KMEB-1/-224 VDC, 230 VAC2.5 / 5 / 10 mSocket cable, LED variant
KMF-1 / KMV-124 VDC, 230 VAC2.5 / 5 / 10 mSocket cable, LED variant
MSSD-C/E/F/V--Valve socket outlet, various versions
MCL / MFL24 VDC/AC, 230 VAC-Indicator plug with LED

Typical applications: Wiring Festo directional control valves and valve terminals in machines and systems, connection of position and pressure sensors to controllers, retrofitting and extending electrical connections on existing pneumatic systems, and commissioning and servicing automation systems with visual indication via LED socket cables.

View as Grid view List view

Items 25-48 of 431

Set Descending Direction
per page
  1. Plug Socket NTSD-GD-9 - Festo 18493
    Add to Wish List Add to Compare
    Plug Socket NTSD-GD-9 - Festo 18493
    €22.99
  2. Connecting Cable VMPA-KMS1-24-5 - Festo 533193
    Add to Wish List Add to Compare
    Connecting Cable VMPA-KMS1-24-5 - Festo 533193
    €82.39
  3. Cable Tie NEAM-B-140-DL-EX2-P10 - Festo 550037
    Add to Wish List Add to Compare
    Cable Tie NEAM-B-140-DL-EX2-P10 - Festo 550037
    €28.31
  4. Connecting Cable KMP3-25P-16-10 - Festo 18625
    Add to Wish List Add to Compare
    Connecting Cable KMP3-25P-16-10 - Festo 18625
    €117.83
  5. Plug Socket MSSD-F-M16 - Festo 539710
    Add to Wish List Add to Compare
    Plug Socket MSSD-F-M16 - Festo 539710
    €3.50
  6. Cable Connector NETC-M-M20-KA - Festo 568279
    Add to Wish List Add to Compare
    Cable Connector NETC-M-M20-KA - Festo 568279
    €34.24
  7. Power Supply Socket NTSD-GD-13,5 - Festo 18526
    Add to Wish List Add to Compare
    Power Supply Socket NTSD-GD-13,5 - Festo 18526
    €23.46
  8. Connecting Cable VMPA-KMS2-24-2,5-PUR - Festo 533501
    Add to Wish List Add to Compare
    Connecting Cable VMPA-KMS2-24-2,5-PUR - Festo 533501
    €101.64
  9. Connecting Cable NEBC-D12G4-ES-5-S-R3G4-ET - Festo 8040453
    Add to Wish List Add to Compare
    Connecting Cable NEBC-D12G4-ES-5-S-R3G4-ET - Festo 8040453
    €43.73
  10. Distributor NEDY-L2R1-V1-M8G3-U-0.3L-M8G4# - Festo 8035485
    Add to Wish List Add to Compare
    Distributor NEDY-L2R1-V1-M8G3-U-0.3L-M8G4# - Festo 8035485
    €27.78
  11. Connecting Cable KM12-8GD8GS-2-PU - Festo 525617
    Add to Wish List Add to Compare
    Connecting Cable KM12-8GD8GS-2-PU - Festo 525617
    €68.28
  12. Plug NECU-S-M8G4-C2 - Festo 1068198
    Add to Wish List Add to Compare
    Plug NECU-S-M8G4-C2 - Festo 1068198
    €17.71
  13. Connecting Cable VMPAL-KM-S-SD25-IP67-2.5 - Festo 560419
    Add to Wish List Add to Compare
    Connecting Cable VMPAL-KM-S-SD25-IP67-2.5 - Festo 560419
    €65.62
  14. Plug Socket MSSD-EB-M12-24VDC-SD-EX - Festo 570367
    Add to Wish List Add to Compare
    Plug Socket MSSD-EB-M12-24VDC-SD-EX - Festo 570367
    €16.87
  15. Plug Socket MSSD-EB-M12-MONO - Festo 188024
    Add to Wish List Add to Compare
    Plug Socket MSSD-EB-M12-MONO - Festo 188024
    €31.13
  16. Connecting Cable NEBC-D12G4-ES-3-S-R3G4-ET - Festo 8040452
    Add to Wish List Add to Compare
    Connecting Cable NEBC-D12G4-ES-3-S-R3G4-ET - Festo 8040452
    €36.26
  17. Connecting Cable KMP3-9P-08-10 - Festo 18579
    Add to Wish List Add to Compare
    Connecting Cable KMP3-9P-08-10 - Festo 18579
    €80.08
  18. Distributor NEDY-L2R1-V1-Z4W2Z-U-0.3L-M12# - Festo 8035787
    Add to Wish List Add to Compare
    Distributor NEDY-L2R1-V1-Z4W2Z-U-0.3L-M12# - Festo 8035787
    €35.48
  19. Plug Socket With Cable KME-1-24DC-5-LED - Festo 30945
    Add to Wish List Add to Compare
    Plug Socket With Cable KME-1-24DC-5-LED - Festo 30945
    €37.26
  20. Power Supply Socket NECU-G78G5-C2 - Festo 543107
    Add to Wish List Add to Compare
    Power Supply Socket NECU-G78G5-C2 - Festo 543107
    €40.78
  21. Connecting Cable NEBV-S1G25-K-2.5-N-LE25 - Festo 538225
    Add to Wish List Add to Compare
    Connecting Cable NEBV-S1G25-K-2.5-N-LE25 - Festo 538225
    €87.95
  22. Plug NECU-S-M12G3-HX - Festo 562027
    Add to Wish List Add to Compare
    Plug NECU-S-M12G3-HX - Festo 562027
    €14.05
  23. Connecting Cable NEBC-D12G4-ES-1-S-R3G4-ET - Festo 8040451
    Add to Wish List Add to Compare
    Connecting Cable NEBC-D12G4-ES-1-S-R3G4-ET - Festo 8040451
    €28.80
  24. Power Supply Socket NECU-M-PPG5PP-C1-PN - Festo 5195383
    Add to Wish List Add to Compare
    Power Supply Socket NECU-M-PPG5PP-C1-PN - Festo 5195383
    €39.04
Page
What is Aventics electrical connection technology and where is it primarily used in industrial applications?
Aventics electrical connection technology encompasses specialized cable assemblies, multi-pole connectors, and interface solutions designed for pneumatic valve manifolds and automation systems. These components are primarily used in automotive manufacturing, packaging machinery, process automation, and material handling systems where reliable electrical connections to pneumatic actuators are critical. The technology includes connector cables like the CL03 series with 8-valve and 16-valve configurations, D-Sub multi-pole connectors with 25-pole and 44-pole variants, and specialized cable assemblies for dynamic applications requiring continuous flexing during operation.
What are the key technical selection criteria for choosing Aventics electrical connection components?
Selection of Aventics electrical connection components depends on the number of controlled pneumatic valves, cable length requirements, and environmental conditions. The CL03 connector cables are available in 5-meter, 10-meter, and 15-meter lengths with either 8-valve or 16-valve configurations to match manifold requirements. Multi-pole D-Sub connectors come in 25-pole and 44-pole versions with straight (180-degree) or angled (90-degree) orientations, while cable jacket materials include PVC for standard environments and PUR (polyurethane) for applications requiring enhanced chemical resistance and flexibility in temperatures ranging from -40°C to +80°C.
Which international standards and certifications apply to Aventics electrical connection technology?
Aventics electrical connection technology complies with IEC 61076 standards for circular connectors and IEC 60947 for low-voltage switchgear connections used in pneumatic control systems. The components meet EN 60529 requirements for ingress protection ratings, typically achieving IP65 or IP67 protection against dust and water ingress when properly mated. Cable assemblies conform to EN 50525 for flexible cables in industrial applications, while the overall system integration follows ISO 4414 pneumatic fluid power standards and EN 60204-1 safety requirements for electrical equipment of machines.
What are the main differences between Aventics CL03 connector cables and D-Sub multi-pole connector variants?
Aventics CL03 connector cables feature pre-assembled plug and socket configurations specifically designed for direct connection to pneumatic valve manifolds, available in 8-valve and 16-valve versions with standardized 5-meter, 10-meter, and 15-meter lengths. D-Sub multi-pole connectors like the R419500471 and R412011258 series provide higher density connections with 25-pole and 44-pole configurations, offering both straight and 90-degree angled orientations for space-constrained installations. The D-Sub variants use robust metal housings with locking mechanisms and are available with either PVC or PUR cable jackets, making them suitable for more demanding industrial environments requiring EMC shielding.
What are the installation requirements and system compatibility considerations for Aventics electrical connections?
Aventics electrical connections require proper strain relief installation with minimum bend radius of 10 times the cable diameter to prevent conductor damage during dynamic applications. The CL03 series connectors feature keyed designs ensuring correct polarity connection to Aventics AV valve manifolds and Series CD01 manifolds, while D-Sub connectors must be mounted with appropriate panel feedthroughs maintaining IP protection ratings. System compatibility extends to 24V DC control voltages with maximum switching currents of 2A per contact, and cable routing must maintain separation from high-voltage power cables according to EN 60204-1 requirements to prevent electromagnetic interference.
What safety ratings and environmental specifications apply to Aventics electrical connection components?
Aventics electrical connection components achieve IP65 to IP67 ingress protection ratings when properly assembled, providing protection against dust ingress and high-pressure water jets in industrial washing applications. Operating temperature ranges extend from -25°C to +80°C for PVC-jacketed cables and -40°C to +80°C for PUR-jacketed variants, with voltage ratings of 300V AC for power connections and signal integrity maintained at frequencies up to 1 MHz. The connectors feature flame-retardant materials meeting UL94-V0 classification and provide vibration resistance according to IEC 60068-2-6 standards, ensuring reliable operation in high-vibration industrial environments.
What maintenance intervals and service life expectations apply to Aventics electrical connection systems?
Aventics electrical connection systems require visual inspection every 6 months for cable jacket integrity, connector housing damage, and proper strain relief attachment, with contact resistance testing annually using standard multimeter measurements not exceeding 50 milliohms per connection. Service life typically ranges from 5 to 10 years in standard industrial environments, with PUR-jacketed cables providing extended service life up to 15 years in applications involving continuous flexing or exposure to hydraulic fluids. Replacement indicators include visible cable jacket cracking, intermittent signal transmission, or measured contact resistance exceeding manufacturer specifications, while preventive replacement scheduling should account for duty cycles exceeding 1 million connection cycles for plug-socket interfaces.
