cab 8936590. Maestro 6/601.70 depanelling machine, cut-off length up to 600 mm

Separation of pre-scored PCBs up to 1,500 mm length with minimum stress on the components
The MAESTRO 6 is the consequent further development of the proven cab depanelling machines.
Even very long panels are separated quickly, economically and stress-free.
The carriage drive is located directly behind the linear knife.
This simplifies the separation and removal of the PCBs considerably.

• Cutting of PCB materials FR 4 and CEM3 up to a length of 600 mm and a component height of 70 mm
• Component height assembly side up to 63 mm, solder side up to 22 mm
• W x H x D: 1150 x 410 x 450 mm
• Weight: 50 kg
• Separation principle: placement side roller blade, solder side linear blade
• Separation process: path-optimized
• Separation speed up to 500 mm/s
• Deposit table depth: 160 mm
• Voltage 100-240 VAC, 50/60 Hz
• Emission sound pressure level LpA < 70 dB (A)
• Approvals CE, FCC Class A
