Festo VZBA-4"-WW-63-T-22-F10-V4V4T (1686705) Ball Valve

Festo
€144,756.00
Excl. 19% VAT , excl. Shipping Cost
Article
FES-1686705

Manufacturer Nr.
VZBA-4"-WW-63-T-22-F10-V4V4T
Ball Valve
Add to Wish List Add to Compare
main product photo
The product may differ from the illustration
Frequently Bought Together
Total price
Construction set up 2-way ball valve
Actuation type Mechanical
Sealing principle Soft
installation position arbitrary
Fastening type pipe installation
Fitting connection Weld ends / weld ends
Switching position display Carriage direction = flow direction
Flange drilling screen F10
Inside diameter [mm] 100,0
Nominal width DN 100
Valve function 2/2
Hand assist actuation none
Flow direction Reversible
Nominal pressure fitting 63
Actuation torque [Nm] 140
Based on standard DIN 3202-S13
ISO 5211
medium Compressed air to ISO8573-1:2010 [-:-:-]
Inert gases
Neutral liquids
Other media on request
Water - no steam
Medium temperature [°C] -10 to 200
Flow Kv [m³/h] 1.414,0
Material information LABS containing materials included
RoHs compliant
Housing material High-alloyed stainless steels
Material number housing 1.4408
Seals material PTFE
PTFE reinforced
Ball material High-alloyed stainless steels
Material number ball 1.4408
Shaft material High-alloyed stainless steels
Material number shaft 1.4401
Product weight [g] 22.300
Corrosion resistant class KBK 3 - severe corrosion stress
CE certificate (see declaration of conformity) to EU pressure vessel directive
More Information
Manufacturer Nr. VZBA-4"-WW-63-T-22-F10-V4V4T
Manufacturer Festo
EAN 4052568245016
Weight 0.100000
HS-Code 84818081
GPSR manufacturer information Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
Article authenticity Original product
Condition of article New
