Bus Node CPX-FB39 - Festo 2093101
Festo pneumatic component for industrial automation and compressed-air applications in proven quality.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Festo pneumatic component for industrial automation and compressed-air applications in proven quality. The key technical data of this genuine Festo article are listed below.
Technical data
| Dimensions W x L x H | 50 mm x 107 mm x 50 mm<br>(Incl. linking block) |
|---|---|
| Parameterising | Systemparameter<br>Diagnoseverhalten<br>Fallback A-Daten<br>Forcen von Kanälen<br>Signal-Setup |
| Additional functions | Start-up parameterisation in text via field bus<br>System status can be shown from process dat<br>Additional diagnosis interface for control panel<br>Acyclical and cyclical data access via sercos<br>IP addressing ia Sercos parameter or control panel<br>Channel related diagnosis via fieldbus |
| Operating element | DIL switch |
| Operating voltage range DC [V] | 18 to 30 |
| Intrinsic power input at operating voltage | Type 100 mA |
| Nominal operating voltage DC [V] | 24 |
| Corrosion resistant class KBK | 1 - low corrosion stress |
| Bearing temperature [°C] | -20 to 70 |
| Protection category | IP65<br>IP67 |
| ambient temperature [°C] | -5 to 50 |
| Product weight [g] | 125,0 |
| Max. address volume outputs [Byte] | 64 |
| Max. address volume inputs [Byte] | 64 |
| Report | Sercos III |
| Material information | RoHs compliant |
| Housing material | PA reinforced |
| Fieldbus interface | 2x Socket M12x1.4-pin, D-coded |
| Device specific diagnosis | Unterspannung Module<br>Diagnose-Speicher<br>Kanal- und modulorientierte Diagnose |
| Configuration support | SDDML file |
| Baud rate | 10/100, full/half duplex MBit/s |
| LED display bus specific | S: Sercos LED<br>SD: Sercos sub-device LED<br>TP1: Network active port 1<br>TP2: Network active port 2 |
| LED display product specific | PL: Load supply<br>SF: System error<br>M: Modify, parameterisation<br>PS: Electronics supply, sensor supply |
| Weight | 0.165 kg |
| Manufacturer | Festo |
| Manufacturer Nr. | CPX-FB39 |
| EAN | 4052568264420 |
| HS-Code | 85176200 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Condition of article | New |
| Article authenticity | Original product |
| Material | Polyamide (PA) |
| Corrosion resistance class CRC | 1 - low corrosion stress |
| Operating voltage | 24 V DC |
| Series | CPX |
| Protection class (IP) | IP65 |
| Temperature (max.) | 50 |
