Festo DPZ-16-10-P-A (32686) Twin-Piston Cylinder

Festo
€37,965.00
Excl. 19% VAT , excl. Shipping Cost
Article
FES-32686

Manufacturer Nr.
DPZ-16-10-P-A
Twin-Piston Cylinder
Add to Wish List Add to Compare
main product photo
The product may differ from the illustration
Frequently Bought Together
Total price
Centre of mass distance of payload to Joch plate [mm] 0
Stroke [mm] 10
Alignable end position range/Length [mm] 10
Piston diameter 16 mm
Operating mode actuator unit Joch
Dampening P: Elastic silencer rings / plates double-sided
installation position arbitrary
Guide sliding guide
Construction set up Guide
Position detection For proximity switch
Operating pressure [bar] 1 to 10
Principle of operation double acting
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Information about operating and control medium Oiled operation possible (required in further operations)
Corrosion resistant class KBK 2 - moderate corrosion stress
ambient temperature [°C] -20 to 80
Impact energy at the end positions [J] 0,15
Max. usable load depending on the stroke at a defined distance xs [N] 21
Theoretical force at 6 bar, Return flow [N] 180
Theoretical force at 6 bar, flow [N] 242
Alternative connections See product drawing
Pneumatic connection M5
Cover material Aluminium wrought alloy
Seals material NBR
Housing material Aluminium wrought alloy
Piston rod material High-alloyed stainless steels
More Information
Manufacturer Nr. DPZ-16-10-P-A
Manufacturer Festo
EAN 4052568114633
Weight 0.410000
HS-Code 84123100
GPSR manufacturer information Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
Article authenticity Original product
Condition of article New
