Drives with guides

Pneumatic drives

Festo drives with guides combine a pneumatic linear actuator and an integrated mechanical guide in a single assembly. Lateral forces are absorbed by the guide element, so the actuator transmits only axial forces and the cylinder is not subjected to bending. The range is divided into drives with guide rods (DFC mini guided cylinders) and drives with slides. Both sub-categories are designed for different load characteristics and installation space requirements.

Categories

Drives with guide rodsDFC mini guided cylinders, bore 4-10 mm, stroke 5-30 mm

Drives with slideSlide actuators with integrated profile rail guide

⚙ Integrated guide - no separate guiding system needed; lateral forces absorbed within the actuator

⬡ Guide rod variant - DFC mini guided cylinders for very small bores (4-10 mm)

✓ Slide variant - for medium to larger loads with high moment capacity at the carriage

✦ Compact unit - actuator and guide form a single installation-friendly assembly

↕ Accurate positioning - guide minimises play and drift at the tool-mounting flange

Guide rod actuators (DFC) are suited to very small bores and compact handling tasks where available space rules out slide actuators. Slide actuators provide higher tipping moment capacity through the wider support base of the profile rail guide and are suited to tooling axes with eccentric loads or larger mounting surfaces.

Typical applications: Gripper and tooling axes in robotics and handling equipment, micro-assembly stations with miniaturised actuator components, infeed and positioning systems with defined footprints, and test rigs with guided lifting movements.
