Festo DSL-32-50-270-CC-A-S2-KF-B (556703) Swivel/Linear Unit
€192,834.00
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-556703
Manufacturer Nr.
DSL-32-50-270-CC-A-S2-KF-B
Swivel/Linear Unit
Frequently Bought Together
-
This Item:
€192,834.00Excl. 19% VAT , excl. Shipping Cost
-
Festo DSL-32-80-270-P-A-S20-B (556519) Swivel/Linear Unit
€133,289.00Excl. 19% VAT , excl. Shipping Cost
-
Festo DRVS-40-180-P-EX4 (2536500) Semi-Rotary Drive
€24,178.00Excl. 19% VAT , excl. Shipping Cost
Total price
| Settings range swivel angle [deg] | 0 to 246 |
| Stroke [mm] | 50 |
| Piston diameter | 32 mm |
| Swivel angle [deg] | 0 to 246 |
| Dampening | CC: Shock absorber, double-sided P: Elastic silencer rings / plates double-sided |
| installation position | arbitrary |
| Fine adjustment [deg] | -3 |
| Principle of operation | double acting |
| Construction set up | Rotary vane |
| Position detection | For proximity switch |
| Variants | continuous piston rod |
| Anti-twist lock / guide | Ball guided |
| Operating pressure [bar] | 2.5 to 8 |
| Max. impact speed [m/s] | 0,5 |
| Max. swivel frequency at 6 bar [Hz] | 0,7 |
| Swivel angle play [deg] | 0,05 |
| Repeatability [deg] | 0,1 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Corrosion resistant class KBK | 1 - low corrosion stress |
| ambient temperature [°C] | -10 to 60 |
| Dynamic load torque [Nm] | 1,00 |
| Theoretical force at 6 bar, Return flow [N] | 294,0 |
| Theoretical force at 6 bar, flow [N] | 403,5 |
| Theoretical torque at 6 bar [Nm] | 10,00 |
| Permitted mass moment of inertia [kg/m²] | 0,00017 |
| Weight supplement per 10 mm stroke [g] | 109 |
| Base weight at 0 mm stroke [g] | 3.280 |
| Product weight [g] | 3.280 |
| Fastening type | clamped in t-slot With Male thread Selectively: |
| Pneumatic connection | G1/8 |
| Cover material | Aluminium wrought alloy anodized |
| Seals material | TPE-U(PU) |
| Housing material | Aluminium wrought alloy Smooth anodised |
| Piston rod material | Quenched and tempered steel |
| Dampening angle [deg] | 12 |
| Manufacturer Nr. | DSL-32-50-270-CC-A-S2-KF-B |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568202026 |
| Weight | 3.900000 |
| HS-Code | 84123900 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
